304 Stainless Steel Lacing Anchors To Connect Insulation Blankets
304 Stainless Steel Lacing Anchors Are Used To Connect Insulation Blankets
1. material of lacing anchor: stainless steel 304/316, mild steel
2.hook head size: 22mm , 25mm, 15mmx22mm
3. pin diameter: 2mm, 2.7mm, 3mm in common.
4. pin length : 63mm, 114mm is most popular. others can be customized.
The Lacing Anchor is a fabricated metal anchor consisting of a pin and tabbed ,or hooked washer . Stainless steel is a popular material while some Lacing Anchors are made in Mild steel . Stamped “no ab “ to denote “no asbestos
Specification details of Stainless Steel Lacing Anchors
| Item | Material | Head Diameter | Head Thick | Pin Diameter | Pin Length | Hook Size |
| Mini round head | SS | 7/8", 22mm | 1mm | 2.0mm,2.7mm | 63.5mm, 114mm | 5x11mm |
| Round head | SS | 30mm | 1mm | 2.0mm,2.7mm | 63.5mm, 114mm | 5x11mm |
| Rectangle head | SS | 20x25mm | 1mm | 2.0mm,2.7mm | 63.5mm, 114mm |
5x11mm |
Images of stainless steel lacing anchor
Related accessories
| Term | specification details of lacing accessories |
| lacing hook |
material: 1mm thickness stainless steel 304 diameter: 25mm / 22mm Type: single hole / double hole hole diameter: 5mm |
| lacing washer |
material: 1mm stainless steel diameter: 25mm hole diameter: 5mm |
| lacing O rings |
material: stainless steel 304/ 316 size: 3mm x30mm |
| lacing D ring |
material: stainless steel 304 / 316 size:3mm x25mmx30mm |
Application :
Lacing Anchors are used in the fabrication of insulation blankets or removable covers/pads. The nail is pressed through the insulation material, so the hook portion sits on the top edge and the nail is secured on the opposite side of the insulation with a washer. The two sides of the blanket can then be "laced" together by the hooks with tie wire..
