1.0μH - 1mH 491R0SC Surface Mount Inductor For Switching Power Supply

Price Negotiable

Price: Supportive

MOQ: 100/500/1000

Delivery Time: Stock or 3 weeks

Brand: Shareway

Product Description

1.0μH to 1mH 491R0SC surface-mount inductors for switching power supply

FEATURES:

RoHS compliant
1.0μH to 1mH
Up to 11.8A IDC
Bobbin format
Surface mount
Integral EMI shield
Compact size
Tape and reel packaging
UL 94V-0 materials
J-STD-020-C reflow

DESCRIPTION:
The 4900S series is a range of bobbin-wound,
surface-mount inductors designed for use in
switching power supply, and power line filter
circuits. The parts are suitable for any application
requiring a high saturation current in a low-profile
package. The devices have an integral ferrite
shield to reduce EMI.

Order Code	Inductance (10kHz, 100mVAC) ±20%	DC Current	DC Resistance	SRF	Q Factor
	Nom.	Max.	Max.	Typ.	Typ.
	μH	A	mΩ	MHz	Q	@ f (MHz)
491R0SC	1.0 (±30%)	11.8	5	91	32	1
492R2SC	2.2 (±30%)	9.8	8	48	45	1
493R3SC	3.3 (±30%)	8.4	10	37	42	1
494R7SC	4.7 (±30%)	7.7	12	32	42	1
496R8SC	6.8 (±30%)	6.2	16	24	43	1
49100SC	10	5.1	21	19	43	1
49150SC	15	4.4	27	16	44	1
49220SC	22	3.1	42	12	46	1
49330SC	33	2.9	60	10	51	1
49470SC	47	2.3	100	9	52	1
49680SC	68	2.0	143	7	47	1
49101SC	100	1.6	165	6	40	0.8
49151SC	150	1.3	250	5	35	0.8
49221SC	220	1.1	380	4	36	0.8
49331SC	330	0.90	550	4	33	0.8
49471SC	470	0.75	810	4	37	0.8
49681SC	680	0.62	1200	3	27	0.8
49102SC	1000	0.50	1500	3	26	0.8
