Automatic Juice Bottle Filling Machine 6.57KW For Coffee Drink Filling / Sealing



Automatic Green Tea, Juiced Beverage Bottling Equipment,

Production Machine Price



Product introduction

This machine integrated sterilizing, rising, filling and capping four functions in one unit, it has

18 rising heads, 18 filling heads and 6 capping heads, can filling 6,000bottles per hour, suitable

for PET bottle, non-gas liquid, like various juiced beverage, water etc.


Machine pictures


Washing part of bottle washing filling capping machine

a) Rotary pan is made of stainless steel 304.

b) The rubber clamp splice seizes the mouth of bottles, which is fixedness and reliable

Filling part of bottle washing filling capping machine

a) Rotary pan is made of stainless steel 304

b) The way of filling is gravitation filling.

c) The filling valve is adopted best stainless steel 304

d) The structure of filling valve is reasonable, the amount is correct

e) When filling the bottle, the bottle is move but the valve is stationary. The splint of bottle-

neck seizes mouth of bottles. The elevator device with the action of gear realize the up and

down of bottle.

Capping part of bottle washing filling capping machine

Capping machine is one of the highest precision machines, which greatly affects the

reliability of device and the defective rate of product. The characteristic is as follows:

a) The dropping cap guide track fixes the device which can protect the cap from turning

over and also set the device which can take out the inverse cap, equip a photo electricity

switch which can stop the machine when lacking the cap and also avoid the situation that

there is bottle without cap.

b) The bottle inlet switch which is set in the capping machine, with the locking cap which is

the connection of the dripping cap guide track and dialing cap pan controls the discharging of

cap, making sure that stop conveyor cap when there is no bottles ,avoid the waste of cap.

electrical system

1) Material of filling valve and liquid tank is 304

2) Main motor:National brand

3) Sliding bearing:Taiwan

4) Frequency inverter: MITSUBISHI

5) Touch screen:Taiwan

6) PLC: MITSUBISHI

7) Pneumatic components: Airtac

8) Seals:National brand


 technical parameter



We are professional in beverage filling machine production, pls tell

us your request, we will show you best proposal... ...
