HW-M80 Connectors, HW-M80-5401205 2mm pitch electric connector
Price:
10＄--150＄
MOQ:
100PCS
Delivery Time:
2--9 weeks
Brand:
HIGH WOOD
Product Description
HW-M80-5401205
The HW-M80-series conectors has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.It is also used in a growing number of medical,and telecom applications, pecializes in the design,development and manufacture of electronic connectors.
Specification:
| Material and coating | |
| Insulating medium | Glass fiber reinforced PPS,UL94-V0 is radiation resistant, non-moisture absorbing and ozone resistant |
| Contact | LF contact: |
| Copper alloy nickel base gold plating | |
| Attachment | Stainless steel |
| Electrical performance index | |
| Pressure resistance (sea level) | 1200V AC/DC |
| Insulation Resistance | ≥1000MΩ |
| Contact | LF contact: working current 25℃≤3A; Working current 85℃, ≤2.2A; Contact resistance ≤10mΩ |
| Mechanical performance index | |
| Mechanical life | 500 cycles |
| Environmental performance index | |
| Working Temperature | -55 ℃ to 125 ℃ |
Product pictures:
