HW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT Connector
Price:
10＄--150＄
MOQ:
100PCS
Delivery Time:
2--9 weeks
Brand:
HIGH WOOD
Product Description
HW-M55-7106842R 1.27mm (0.05") Pitch PCB Horizontal SMT Connector
HW-M55-7106842R
PRODUCT DESCRIPTION
- Double Row Surface Mount, 10mm total footprint depth, shrouded polarized connector – 68 contacts (34+34). Location pegs, surface mount hold-down retaining tabs for additional solder strength.
- Board stacking connectors for 90 degree or coplanar board-to-board connection. Supplied in Tape and Reel. Gold finish on contact area, Tin finish on termination.
SPECIFICATION
Contact Pitch:
1.27mm (0.05")
Contact Gender:
Male/Plug
Connector Orientation:
Horizontal
Connection Type:
Surface Mount (SMT)
Current Rating:
1.2A max per contact
Operating Temperature:
-55°C to +125°C
Soldering Data:
Max Solder Temperature: 260°C for 10 seconds
Polarising Features:
Yes
End Stackable:
No
Side Stackable:
No
Can be cut to another size:
No
Number of Rows:
2
Number of Signal Contacts:
68
MATERIALS
Finish / Plating on Termination:
100% Tin over Nickel
Finish / Plating on Contact Surface:
Gold
Base Material of Contact:
Phosphor Bronze
Housing Material:
LCP
Housing Colour:
Black
Housing Material UL Rating:
UL94V-0
Product pictures:
