3528 4.8W Flexible LED Strip Lights 8mm Width Ounce PCB For Automobile Decoration
High Brightness Flexible Led Strip Lights 3528 4.8W 60 led/meter 8mm width ounce PCB
Quick details :
1) SMD 3528 led used .
2) 60led/m and 4.8W
3) No harmful UV rays
4) CRI 80+, CRI 90+available
5) 50,000 hour life
6) 120° Viewing Angle
7) Superbrightness,even Illumination - No Shadowing
8) Utilizes 3M Double Stick Mounting Tape
9) Certification: CE&ROHS
10) Warranty period: three years .
Product description:
3528 non-waterproof flexible LED strip, 60 LEDs/m
Product:3528 non-waterproof flexible LED strip, 60 LEDs/m
Dimension: L5000mm*W8mm*H0.25mm
LED quantity: 300 SMDs/pcs, 60 3528SMDs/m
Thickness of PCB: 0.25mm
Working voltage: DC 12V/24V,every 3 LEDs can be cut(12VDC), or every 6 LEDs can be cut(24VDC),
Power dissipation:4.8W
Working current: 2A/reel, or 1A/reel.
Viewing angle: 120 degree
Packing: 5m/reel
Color: red, yellow, blue, green, white and warmwhite are available
Color of PCB: white, brown, black are available.
Product specification:
| Ordering Code | Colors Available | LED features | LED Q’ty/m |
CRI | Typ Lum. intensity (lm/m) | PCB | Voltage (VDC) |
Max Power (W/m) |
Waterproof Grade available (IP) |
| PS3528CW12060IP20 | Cool white | 6000K~6500K (CCT) | 60 | CRI 80+ | 400 | White color width 5/8mm |
12(24) | 4.8 | IP20 /(IP65/IP67/IP68) |
| PS3528NW12060IP20 | Neutral white | 4000K~4500K (CCT) | 400 | ||||||
| PS3528WW12060IP20 | Warm white | 3000K~3500K (CCT) | 400 | ||||||
| PS3528R12060IP20 | Red | 620nm~630nm (WL) | - | ||||||
| PS3528Y12060IP20 | Yellow | 580nm~590nm (WL) | - | ||||||
| PS3528B12060IP20 | Blue | 460nm~470nm (WL) | - | ||||||
| PS3528G12060IP20 | Green | 520nm~530nm (WL) | - |
Product applications:
1) Architectural deco2) Archway, canopy rative lighting & bridge edge lighting
3) Amusement park, theater & aircraft cabin mood lighting
4) Emergency hallway lighting
5) Auditorium walkway lighting
6) Stairway accent lighting
7) Concealed lighting
8) Backlighting for signage letters
9) Channel letter lighting
10) Cove lighting
Packing & Delivery:
