4660-5390 Lm 40 W A1919 COB LED Diode Aluminum Base High CRI 80 For Down Light
40 W Aluminum Base A1919 Series COB LED With High CRI 80 For Down Light
Feature :
1. High reliability,low thermal resistance,long life span,LM90.
2. Good consistency,macadam 3/5 SDCM.
3. Stable supply and delivery guarantee.
4. Fast response.
5. Low cost, easy assembly characteristics
6. Lead free, RoHS -compliant.
Application :
1. High Bay Light
2. Flood Light
3. COB Down Light
4. LED Track Light
5. Project Lamp
6. Spot Light
Description :
The white led which was fabricated using a blue chip and phosphor .
Parameter :
| Part No. | If (mA) | VF(V) | lm | Watt | efficacy(lm/w) | CCT(K) | CRI(min) |
| A19A-W2*T4012-C4 | 1200 | 36 | 4660 | 40 | 115 | 2700K | 80 |
| A19A-W3*T4012-C4 | 1200 | 36 | 4850 | 40 | 120 | 3000K | 80 |
| A19A-W4*T4012-C4 | 1200 | 36 | 5200 | 40 | 128 | 4000K | 80 |
| A19A-W5*T4012-C4 | 1200 | 36 | 5300 | 40 | 132 | 5000K | 80 |
| A19A-W7*T4012-C4 | 1200 | 36 | 5390 | 40 | 135 | 6500K | 80 |
Note:
1. 1/10 Duty cycle, 0.1ms pulse width.
2. The above forward voltage measurement allowance tolerance is 0.1V.
3. The below color coordinates measurement allowance tolerance is 0.003.
4. the above luminous flux measurement allowance tolerance ±10%.
5. Care is to be taken that power dissipation does not exceed the absolute maximum rating of the product.
6. All measurements were made under the standardized environment of Refond.
7.When the LEDs are in operation the maximum current should be decided after measuring the package temperature,junction temperature should not exceed the maximum rate.LED
