316 Stainless Steel Rope Aviary Wire Netting High-Strength Load-Bearing
316 Stainless Steel Rope Aviary Wire Netting High-Strength Load-Bearing
Aviary Wire Netting Specification As following :
Aviary Wire Netting Made of stainless steel and crafted via steel wire rope weaving, it has high tensile strength, can bear large loads, and is suitable for scenarios such as high-altitude protection and heavy object hoisting.
Stainless steel components (e.g., grades 304, 316) can resist erosion from humid, acidic, and alkaline environments, and are not prone to rusting during long-term use, extending their service life.
The Aviary Wire Netting holes are regularly distributed without blocking light. When used for building exterior walls and balcony protection, it maintains the lighting effect of the space without affecting the field of view.
Recommended Stainless Steel Cable Mesh Specification for Aviaries :
| Material | Cable Diameter | Hole Size | Normal Break |
| SS304/316/316L | 3/64" (1.2MM) | 1" x 1" | 270 LBS |
| SS304/316/316L | 1/16" (1.6MM) | 1" x 1" | 480 LBS |
| SS304/316/316L | 1/16" (1.6MM) | 1.2" x 1.2" | 480 LBS |
| SS304/316/316L | 5/64" (2.0MM) | 1.2" x 1.2" | 676 LBS |
| SS304/316/316L | 5/64" (2.0MM) | 1.5" x 1.5" | 676 LBS |
| SS304/316/316L | 5/64" (2.0MM) | 2.0" x 2.0" | 676 LBS |
Wire rope aviary mesh netting is manufactured from high-grade stainless steel cables of material class 1.4401, AISI316 / AISI316L ;
Aviary Wire Netting by Yuntong made from stainless steel wires, and has skin-like characteristics. It can form a plane surface but can also be tensioned into three-dimensional forms featuring funnel-like, cylindrical or spherical.
The Mesh is custom manufactured to in widths and lengths to suit your architectural application. Diagonal and irregular shapes can also be supplied.
Mesh can be applied in either a vertical or horizontal direction, again dependent on the design and the required aesthetics.
Our aviary wire mesh netting ange from ferruled wire rope mesh , knotted wire rope mesh to various installation's accessories . Also we can provide black oxide wire rope mesh .
