4mm Carbon Steel Fiber Laser Tube Cutting Machine 500w - 4000W With Raytools
4mm Carbon Steel Tube Pipe Sheet CNC Fiber Laser Cutting Machine with Raytools
Fiber laser cutting machine adds tube cutting function, meeting requirements for both plate metal and tube cutting. One machine for multiple uses.
Application of manual clamping chuck with extra-long mechanic claw to reduce material waste. Processing diameter falls between 20mm--200mm, which could meet most of the tube cutting requirements. Synchronized electric servo motor-driven chucks at both front and rear ends.
Technical Parameters
|
Laser type |
Maxphotonics fiber laser |
|
Laser power |
500w 750w 1000w 2000w 3000w fiber optional |
|
Cutting area |
1500mm*3000mm |
|
Whole machine size |
1360*780*1100mm |
|
Engraving speed |
0 - 60,000mm/min |
|
Resetting positioning accuracy |
±0.05mm |
|
Working voltage |
AC 110 - 220V±10%, 50 - 60Hz |
|
Gross power |
<1,000W |
|
Operating temperature |
0 - 45°C |
|
Operating humidity |
5- 95% |
|
Minimum shaping character |
English 1 x 1mm |
|
Graphic format supported |
BMP,PLT, DST, DXF, and AI |
|
Driving system |
500w 750w 1000w 2000w 3000w fiber optional |
|
Cooling mode |
water-cooling and protection system |
|
Auxiliary equipments |
Exhaust-fans, air-exhaust pipe |
|
Controlling software |
Cypcut control system |
|
Compatible software |
CorelDraw AutoCAD Photoshop |
|
Net Weight |
6000kg(depends on models) |
Certification
Application:
Widely used in the processing of advertising board, metal plate structure, Hv/lv electrical ark production, textile machinery parts, kitchen utensils, car, machinery, elevator, electric parts, spring coil slice, subway line spare parts, etc..
