PVD Decorative Vacuum Plating Machine, Cathodic Arc Deposition System For Bathroom Fittings Decorative Colors
Bathroom Fittings Arc Ion Plating Machine / Bathroom Accessories Decoration Vacuum Plating
We assist our customers to select the proper coating process and coating machine based on the products material and coating capacity.
Bathroom Fittings Arc Ion Plating Machine is with the PVD vacuum arc discharge technology to evaporate targets and condense ions on product surface. The evaporation source (cathode) is ignited in a vacuum environment forming a self-sustaining arc discharge with the anode releasing target material ions from the cathodic arc radiant point. Due to the local current focus, the heat generated a localized ionization of the cathode material that, when combined with the reaction gas under the action of the workpiece bias, the deposits a plated film on the workpiece surface.
PVD Titanium coating on bathroom accessory Properties :
Finishing Properties: The machine is used to deposit TiN(gold color) ,Ti (silver color) and other coating on sanitary, After coating , it looks bright, metallic, smooth, and it's rust-proof,water proof. have a long life time.
Bathroom Fittings Arc Ion Plating Machine Specification
| MODEL | RTAC1416 | ||||||
| TECHNOLOGY | plasma, ion plating,, cylindrical target | ||||||
| MATERIAL | Stainless Steel (S304) | ||||||
| CHAMBER SIZE | Φ1400*1600mm (H) | ||||||
| CHAMBER TYPE | Cylinder, vertical, 1-door | ||||||
| EVAPORTATION SYSTEM | EXCLUSIVE DESIGN FOR BATHROOM ACCESSORY | ||||||
| DEPOSITION MATERIAL | Titanium,Silver, Copper, Chrome, Stainless Steel, Aluminum,Nickel | ||||||
| CONTROL | PLC(Programmable Logic Controller) + Touch Screen | ||||||
| PUMP SYSTEM | Rotary Pistonr Vacuum Pump SV300B *2 | ||||||
| Rotary Vane Vacuum Pump D60C *1 | |||||||
| Roots Vacuum Pump WAU1001 *1 | |||||||
| Molecular Pump KYKY F3500/400 *3 | |||||||
| PRE-TREATMENT | Bias Plasma Cleaning | ||||||
| SAFETY SYSTEM | Numerous safety interlocks to protect operators and equipment | ||||||
| COOLING | Cold Water | ||||||
| POWER ELECTRICAL | 480V/3 phases/60HZ ( USA compliant) | ||||||
| 460V/3 phases/50HZ ( Asia compliant) | |||||||
| 380V/3 phases/50HZ ( EU-CE compliant) | |||||||
| FOOTPRINT | L6000*W3400*H2500mm | ||||||
| TOTAL WEIGHT | 7 T | ||||||
| CYCLE TIME |
40 minutes (depending on substrate material, substrate geometry and environmental conditions) |
||||||
| POWER MAX.. | 60KW | ||||||
| AVERAGE POWER CONSUMPTION (APPROX.) | 40KW |
Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
