Stainless Steel Forks Gold Plating Machine

Price Negotiable

Price: negotiable

MOQ: 1 set

Delivery Time: 12 weeks

Brand: ROYAL

Product Description

Stainless steel flatware PVD Brass and Bronze Coating Machine, Forks TiN gold Plating Equipment

Tableware TiN Gold Coating Machine Advantages

1. Economically efficient, generating the thinnest, most uniform coating films;
2. A dry coating process at low temperature in a vacuum chamber;
3. Offers great versatility and can be used for the deposition of conductive or non-conductive materials on any type of substrates, like: metals, ceramics, plastic materials.
4. Multi-layered coating are simple to produce.

5. Fast deposition rates and high quality surface finishes.

Tableware TiN Gold Coating Machine Specifications

MODEL				RTAS1200
TECHNOLOGY				Magnetron Sputtering + Ion Plating
MATERIAL				Stainless Steel (S304)
CHAMBER SIZE				Φ1200*H1500mm
CHAMBER TYPE				Cylinder, vertical, 1-door

DEPOSITION MATERIAL				Aluminum, Silver, Copper, Chrome, Stainless Steel, Nickel, Gold, TiAl, Au alloy, Ag etc.
DEPOSITION SOURCE				14 sets steered arc cathodes
GAS				MFC- 4 ways, Ar, N2, O2, C2H2
CONTROL AND OPERATION				PLC(Programmable Logic Controller) + Touch Screen
PUMP SYSTEM				SV300B - 2 sets (Leybold)
				WAU1001 - 1 sets (Leybold)
				D60T- 1 set (Leybold)
				Turbo Molecular Pumps: 3* F-400/3500
PRE-TREATMENT				Bias power supply: 1*36 KW
SAFETY SYSTEM				Numerous safety interlocks to protect operators
COOLING				Cold Water
POWER ELECTRICAL				480V/3 phases/60HZ ( USA compliant)
				460V/3 phases/50HZ ( Asia compliant)
				380V/3 phases/50HZ ( EU-CE compliant)
FOOTPRINT				L3000W3000H2000mm
TOTAL WEIGHT				7.0 T
FOOTPRINT				( LWH) 50004000 4000 MM
CYCLE TIME				30~40 minutes (depending on substrate material, substrate geometry and environmental conditions)
POWER MAX..				155 KW
AVERAGE POWER CONSUMPTION (APPROX.)				75 KW
