Gold Tin Coating Equipment For Ceramic Tiles , Titanium Nitride Pvd Plating Machine
Price:
negotiable
MOQ:
1 set
Delivery Time:
9 to 12 weeks
Brand:
ROYAL
Product Description
TiN gold coating on Ceramic Tiles, Arc Vacuum PVD Plating Equipment
By using PVD arc evaporation coating technology, deposit many metal materials like: Titanium, Chrome, Copper, Brass, Zirconium to get various colors: gold, silver, black, grey, chroming.
The PVD Arc Vacuum coating equipment consists of: vacuum chamber, vacuum pumps, arc sources, spindle & jack, jigs structure, heating & cooling, water & gas (distribution), electrical control & operation systems, substrate carrier etc.
Ceramic TiN Coating Equipment Advantage: easy to operate, compact foot print, low cost of owner ship, fast substrate exchange.
TiN Coating Film's properties: high shiny and bright colors, strong adhesion & excellent scratch protection.
The RTAC2022 coating machine has large capacity to guaranty 200 ~300 squre meters coating every 8 hours.
RTAC2022 Specification
| MODEL | RTAC2022 | ||
| MATERIAL | Stainless Steel (S304) | ||
| CHAMBER SIZE | Φ2000*2200mm (H) | ||
| PUMP SYSTEM | Rotary Piston Vacuum Pump (Mechanical) | ||
| Rotary Vane Vacuum Pump (Holding) | |||
| Roots Vacuum Pump | |||
| Diffusion Pump | |||
| TECHNOLOGY | Ion Plating ( Multi-arc sources) | ||
| TYPICAL TARGETS | Titanium, Chrome, Zr, Cu, Al etc. | ||
| GAS | Gas Mass Flow Meters ( Ar, N2,) (Argon, Nitrogen ) | ||
| CONTROL | PLC(Programmable Logic Controller) | ||
| SAFETY SYSTEM | Numerous safety interlocks to protect operators and equipment | ||
| COOLING | Water | ||
| HEATING | Heater | ||
| POWER MAX. | 150 KW (Approx.) | ||
|
AVERAGE POWER CONSUMPTION |
70 KW (Approx.) | ||
Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
