General Information
The PVD Vacuum Hard Chrome coating process has been used in the automotive industries for decades. Sputtering Chrome/Aluminum on Aluminum alloy rims is a standard application due to its 100% environmentally friendly process and resistance to pitting or peeling off like traditional water-electroplating. The high abrasion resistance coating forms a durable film that greatly enhances the car rim’s lifetime. For these reasons and ease of use and reliability the PDV hard chrome coating is welcomed by the automotive factories.
RTSP2022 Advantages:
The RTSP1618 Magnetron Sputtering Chrome PVD coating machine is exclusive designed for the automotive rims manufacture, the high production and fast deposition speed, durable coating layers properties are highly comment by our final users.
| MODEL | RTSP2022 | ||
| MATERIAL | Stainless Steel (S304) | ||
| CHAMBER SIZE | Φ2022*1800mm (H) | ||
| CHAMBER TYPE | Cylinder, vertical, 2-doors | ||
| SINGLE PUMP PACKAGE | Mechanical Vacuum Pump: Leybold SVC300/SVC630BF | ||
| Holding Vacuum Pump: Leybold D60C | |||
| Roots Vacuum Pump: Leybold Vacuum Pump: WAU4400 | |||
| Diffusion Pump: Leybold High Vacuum Oil Diffusion Pump: | |||
| TECHNOLOGY | Magnetron Sputtering | ||
| POWER SUPPLY | DC power supply | ||
| DEPOSITION SOURCE | Planar Sputtering Target | ||
| CONTROL | PLC+Touch Screen | ||
| GAS | Gas Mass Flow Meters | ||
| SAFETY SYSTEM | Numerous safety interlocks to protect operators and equipment | ||
| COOLING | Cooling Water | ||
| CLEANING | Glow Discharge Cleaning | ||
| POWER MAX. | 100 KW | ||
|
AVERAGE POWER CONSUMPTION |
55 KW | ||
Please contact us for more specifications, Royal Technology is honored to provide you total coating solutions.
