5800mm Length Well Casing Screen , Industrial Water Well Sand Screen
10 " Vee Wire Low Carbon Steel Galvanized Wound Well Screen Pipe
Product Description:
10 " Wound Well Screen is manufactured with V-shaped profile wire which is spirally wound around a cage of longitudinal support rods. Each intersecting point of these wires is fusion welded. The pitch of winding gives different spacing between two adjacent turns of wire. This spacing gives passage for water to enter. The entire process is completed on fully computerized machines.
.
Specification:
| Material | Low carbon steel galvanized |
| Grade | Q195, Q235 |
| O.D | 273 mm |
| Size | 10-3/4 " |
| Slot size | 0.5mm, 0.75mm, 1.0 mm |
| Length | 5.8m |
| End connection | Welded rings |
| Wire size | 3*4.6mm, 3*5mm, 3*6mm, 3*7mm |
| Support rod | round wire, ø3.0-5.0mm |
| No. of support rod |
55 PCS, 64 PCS |
| Weight | 31-38KG / meter |
Special specification can be made according to your drawing!
Advantages:
1. Adoption of the wedged wires made a V profile slot. This design ensures the fluent of water filtration and more effective
2. Wedged wires are spirally wound around a cage of longitudinal support rods in succession which formed high-density uniformed slots and avoid clogging. So that the high production efficiency and long life service of the well are guaranteed.
3. Arrangement of the longitudinal support rods and the successive slots provide higher compressive property
