Meeting Room Rgb Indoor Rental Led Screen Pixel Pitch 2.5mm 3840HZ Refresh Rate
P2.5 Indoor Die Casting aluminum display screen P2.5 led video wall indoor SMD 3in 1 rgb led display
Product Quick Details:
A, Pixel pitch: 2.5mm
B, IC: MBI5153
C, Refresh rate: 3840HZ
D, Brightness: 800CD
Product Features:
1, High refresh rate 3840HZ, MBI 5153 is used, remove ghost without trailing, could meet high-end demands of clients, such as TV studio.
2, High quality SMD 1010 with low failure is used, it has a great performance in stability, lowest light mulfunction, great color consistence as well as heat dissipation.
3, High grey scale under low brightness:The high quality full black leds, together with black mask, achieves clear and crystal picture.
4, Support single pixel color brightness calibration and single color brightness cablibration, ensures higher color uniformity and higher brightness uniformity of each screen.
Parameter
| ※Specifications of LED modules | ||||
| Technical parameters | UNIT | Parameters values | ||
| Pixel pitch | MM | 2.5 | ||
| Panel size | MM | L160*H160*T13 | ||
| Physical density | /M2 | 160000 | ||
| Pixel configuration | R/G/B | 1,1,1 | ||
| Driving method | 1/32 Constant current 1/32scan | |||
| LED Encapsulation | SMD | 2121 | ||
| Display resolution | DOTS | 64X64=4096 | ||
| Module weight | KG | 0.19 | ||
| Module port | HUB-HD01 | |||
| Module working voltage | VDC | 5 | ||
| Module consumption | W | 35 | ||
| ※Specifications of cabinet | ||||
| Cabinet size | mm | 480*480 | ||
| Cabinet weight | kg | 5 | ||
| Cabinet resolution | dots | 192*192 | ||
| Viewing angle | Deg. | 140° | ||
| Option distance | M | 2-30 | ||
| Driving device | 2016/5020 | |||
| Every square meter module | PCS | 39.06 | ||
| Maximum power | W/ M2 | 1400 | ||
| Frame Frequency | HZ/S | ≥60 | ||
| Refresh frequency | HZ/S | ≥320 | ||
| Equilibrium brightness | CD/ M2 | ≥1500 | ||
| Working environment temperature | 0C | -10~60 | ||
| Working environment humidity | RH | 10%～70% | ||
| Display working voltage | VAC | AC46～54HZ,220V±15%/110V±15% | ||
| Color temperature | 8500K-11500K | |||
| Gray scale/color | ≥16.7M color | |||
| Input signal | RF S-Video RGB etc | |||
| Control system | PCTV nonlinearity card, DVI display card,Linsn control system | |||
| Mean free error time | HOURS | ＞5000 | ||
| Life | HOURS | 100000 | ||
| Lamp failure frequency | ＜0.0001 | |||
| Antijam | IEC801 | |||
| Safety | GB4793 | |||
| Resist the electricity | 1500V last 1min No breakdown | |||
| Steel box weight | KG/ M2 | 40(standard steel box) | ||
| Earth leakage current | mA | |||
| IP rating | The back IP40,The front IP50 | |||
| Steel box size | mm | L640Xh640x80 | ||
Aging test
