High Brightness Outdoor Rental LED Display SMD 2727 1/13 Scan Mode 38.5W
High Brightness Outdoor Rental LED Display SMD 2727 1/13 Scan Mode 38.5W
Product Description
1.High brightness Contrast:4000:1, which is a very high level to ensure a vivid image of our LED display screen system
2. First-class LED chip to ensure the long lift-time and high brightness of our LED display screen system
3.Clear vivid image quality even in direct, full-on sunlight to ensure you attracts more audience
4.Long-term Brightness:More 7000-nit brightness(for outdoor full color)(2000 nits brightness for indoor full color)capacity throughout product lifetime of the LED display screen.
5.Easy Installation & Using: easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
6.Convenient Servicing: Front and rear cabinet access make the maintance work very convenient and low cost.
OUTDOOR P4.81 SMD 3IN1 TECHNICAL PARAMETERS
| Unit Module | Item | Parameter |
| Model Number | SF-SS4.81-13S-A | |
| Module size | 250mm*250mm | |
| Pixel pitch | 4.81mm | |
| Pixels Density | 43264 dot/m2 | |
| Pixel configuration | 1R1G1B | |
| Package mode | Nationstar SMD2727 | |
| Pixel resolution | 52dots(W)*52 dots (H) | |
| Max Power | 38.5W | |
| Weight | 0.58kg | |
| Drive type | Constant drive | |
| Scan mode | 1/13 | |
| Port type | HUB75-A | |
| Brightness of white balance | ≥4850cd/m2 |
|
LED Cabinet |
Dimension | 500mm*500mm |
| Monomer Module Number | 4pcs | |
| Power supply | 5V/60A*1pcs | |
| Thermal discharge | fan 2pcs | |
| Pixel per cabinet | 104mm*104mm | |
| Best viewing distance | 2M～14M | |
| Best viewing angle | 110°(W) 110°(H) | |
| Temperature |
storage:-35℃～+85℃ working:-20℃～+50℃ |
|
| Relative humidity | 10%-95% | |
| Thickness | 100mm |
| ower | Working voltage | AC110～220V±10% |
| Average Power consumption | 200W/㎡ | |
| Max Power consumption | <400W/㎡ | |
| Current | <20mA(single LED) | |
| Control system | CPU | Pentium4 or above P4 |
| Operation system | WIN98/2000/NT/XP/WIN7 | |
| Control method | Synchronization | |
|
Main technical parameter |
Driving device | Constant drive IC |
| Refresh frequency | >1920HZ | |
| Grey scale/colors | 16384gray level/16.7M colors | |
| MTBF | >9000hours | |
| Power switch | Automatic switch | |
| Display Mode | ≥800*600/1024*768 |
2. The display adopts high refresh rate, no highlights, perfectly meet the requirements of
video image
3. Excellent visual effect, better viewing effect for text and graphic or video.
4. Easy operation and control, simple installation and maintainence.
5. Long lifespan up to 9,000 hours.
