China HOWO NX 8*4 400 Horsepower Dump Truck With 31-40 Ton Loading Capacity Tipper Trucks 40 ton 12 Wheel Dump Truck

Price Negotiable
Price: USD23100-25410
MOQ: 1 UNIT
Delivery Time: 45 Work days
Brand: Howo
Product Description

China HOWO NX 8*4 400 Horsepower Dump Truck With 31-40 Ton Loading Capacity Tipper Trucks 40 ton 12 Wheel Dump Truck



Model
ZZ3257V3847B1
Driver's Cab
HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine
Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6
cylinder in-line with water cooling, turbo-charging & inter cooling.
Maximum output: 400PS (294kW) at 2100 rpm
Maximum torque: 2060Nm at 1200-1500rpm
Bore: 126mm Stroke: 155mm
Displacement: 11.596L
Brand: Weichai
Steering
Model: BOSCH
Hydraulic steering with power assistance
Left hand driving
Clutch
Φ430 Pull-type diaphragm spring clutch
Transmission
Model: HW19710, 10 forward and 2 reverse
Manual type
With transmission power take-off HW70
Max Torque: 1900N·M
Front Axle
Model: HF9
Drum brake system
Rated loading capacity :9000kgs
Rear Axle
Model: MCP16ZG
Capacity: 16000kgs
Drum braking steering axle,self-adjusting arm
Speed ratio:
Wheelbase
3800+1350 mm
Brake System
Type :Wabco braking system
ABS 4S/4M
Engine exhaust valve brake
Oil Tanker
300L aluminum alloy fuel tank
Tires
Types: 12.00R20 radial tire; 18PR
10 pcs, plus one pc spare tire
Bumper
Metal bumper
Dump body
5600*2300*1500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral
fender, headlight cover.
Dimensions in mm
Front wheel track (mm): 2022
Rear wheel track (mm):1830
Overhang(front/rear) (mm):1500/1870
Overall Dimension (mm): 8650*2580*3450
Weight in kg
Dead weight (kg):13500
Gross vehicle weight (kg):25000


A dump truck is a specialized vehicle designed primarily for transporting and dumping loose materials

such as sand, gravel, dirt, and debris. It features a large, open-box bed that is hydraulically operated

to tilt or raise at the front, allowing the contents to be unloaded easily. Dump trucks are commonly used

in construction, mining, landscaping, and agriculture, where the efficient movement and deposition of

bulk materials are essential.

Key features of a dump truck include:

  1. Open-Box Bed: This is the main distinguishing feature of a dump truck. The bed can be raised

  2. or tilted to one side, allowing the material inside to be discharged.

  3. Hydraulic System: Most dump trucks are equipped with hydraulic cylinders that power the tilting

  4. mechanism of the bed. This hydraulic system enables controlled and efficient dumping of materials.

  5. Heavy-Duty Construction: Dump trucks are built with robust frames and chassis to withstand

  6. heavy loads and rugged terrain conditions.

  7. Variety of Configurations: Dump trucks come in various sizes and configurations to accommodate

  8. different payload capacities and operational requirements. They can range from small trucks used

  9. for residential construction to large, off-road models used in mining and quarry operations.

  10. Versatility: Beyond transporting materials, dump trucks can be used for tasks such as excavation,

  11. grading, and hauling. They are versatile tools in industries where earthmoving and material handling

  12. are crucial.

Overall, dump trucks play a vital role in facilitating construction projects, mining operations, and other

industrial activities by efficiently transporting and depositing materials at the desired locations. Their design

and functionality are tailored to meet the demanding requirements of heavy-duty applications.
