Hot HOWO TX Dump Truck 6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality

Name: Hot HOWO TX Dump Truck 6x4 10 Wheel Howo 380HP Tipper Truck Price High Quality
Brand: Jinan Heavy Truck Import & Export Co., Ltd.

Price Negotiable

Price: USD23100-25410

MOQ: 1 UNIT

Delivery Time: 45 Work days

Brand: Howo

Product Description

Hot HOWO TX Dump Truck 6x4 10wheel Howo 380HP Tipper Truck Price High-Quality

Model	ZZ3257V3847B1
Driver's Cab	HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine	Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling. Maximum output: 400PS (294kW) at 2100 rpm Maximum torque: 2060Nm at 1200-1500rpm Bore: 126mm Stroke: 155mm Displacement: 11.596L Brand: Weichai
Steering	Model: BOSCH Hydraulic steering with power assistance Left hand driving
Clutch	Φ430 Pull-type diaphragm spring clutch
Transmission	Model: HW19710, 10 forward and 2 reverse Manual type With transmission power take-off HW70 Max Torque: 1900N·M
Front Axle	Model: HF9 Drum brake system Rated loading capacity :9000kgs
Rear Axle	Model: MCP16ZG Capacity: 16000kgs Drum braking steering axle,self-adjusting arm Speed ratio:
Wheelbase	3800+1350 mm
Brake System	Type :Wabco braking system ABS 4S/4M Engine exhaust valve brake
Oil Tanker	300L aluminum alloy fuel tank
Tires	Types: 12.00R20 radial tire; 18PR 10 pcs, plus one pc spare tire
Bumper	Metal bumper
Dump body	560023001500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral fender, headlight cover.
Dimensions in mm	Front wheel track (mm): 2022 Rear wheel track (mm):1830 Overhang(front/rear) (mm):1500/1870 Overall Dimension (mm): 865025803450
Weight in kg	Dead weight (kg):13500 Gross vehicle weight (kg):25000

A dump truck is a powerful and versatile vehicle designed for transporting and unloading bulk materials. Here's an in-depth look at dump trucks:

Standard Dump Truck:
- Configuration: Truck chassis with a mounted dump body.
- Operation: The bed is lifted using a hydraulic ram, dumping materials at the rear.
Articulated Dump Truck (ADT):
- Configuration: Consists of two parts: a tractor and a trailer, joined by a pivot point.
- Operation: Offers better maneuverability on rough terrain due to its articulation.
Transfer Dump Truck:
- Configuration: A standard dump truck pulling a separate trailer with an additional dump bed.
- Operation: Allows for greater load capacity by using an additional dump trailer.
Side Dump Truck:
- Configuration: Dump body capable of tilting to the side.
- Operation: Efficient for quickly unloading materials to the left or right side.
Super Dump Truck:
- Configuration: Enhanced standard dump truck with additional axles.
- Operation: Increases payload capacity and distributes weight more effectively.
Dump Trailer:
- Configuration: A trailer equipped with a hydraulic lift, towed by another vehicle.
- Operation: Used for transporting bulk materials with the convenience of detaching the trailer.

Capacity: Measured in cubic yards or tons, indicating how much material can be carried.
Hydraulic System: Powers the lifting mechanism for unloading materials.
Chassis: The structural frame supporting the dump body.
Axles and Tires: Designed to support heavy loads and provide stability.
