Second Hand HOWO 6x4 336hp 10 Wheeler 20 Cubic Meters Sinotruck Howo Dump Tipper Truck For Sale

Name: Second Hand HOWO 6x4 336hp 10 Wheeler 20 Cubic Meters Sinotruck Howo Dump Tipper Truck For Sale
Brand: Jinan Heavy Truck Import & Export Co., Ltd.

Price Negotiable

Price: USD23100-25410

MOQ: 1 UNIT

Delivery Time: 45 Work days

Brand: Howo

Product Description

Second Hand HOWO 6x4 336hp 10 Wheeler 20 Cubic Meters Sinotruck Howo Dump Tipper Truck For Sale

Model	ZZ3257V3847B1
Driver's Cab	HW76 extended cab, with one sleeper berth ,with air conditioner, air seat for driver. MP3
Engine	Model: WP12.400E201, Euro II emission standard, 4 stroke injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & inter cooling. Maximum output: 400PS (294kW) at 2100 rpm Maximum torque: 2060Nm at 1200-1500rpm Bore: 126mm Stroke: 155mm Displacement: 11.596L Brand: Weichai
Steering	Model: BOSCH Hydraulic steering with power assistance Left hand driving
Clutch	Φ430 Pull-type diaphragm spring clutch
Transmission	Model: HW19710, 10 forward and 2 reverse Manual type With transmission power take-off HW70 Max Torque: 1900N·M
Front Axle	Model: HF9 Drum brake system Rated loading capacity :9000kgs
Rear Axle	Model: MCP16ZG Capacity: 16000kgs Drum braking steering axle,self-adjusting arm Speed ratio:
Wheelbase	3800+1350 mm
Brake System	Type :Wabco braking system ABS 4S/4M Engine exhaust valve brake
Oil Tanker	300L aluminum alloy fuel tank
Tires	Types: 12.00R20 radial tire; 18PR 10 pcs, plus one pc spare tire
Bumper	Metal bumper
Dump body	560023001500mm, 8mm for bottom and 6 mm for side plate, rectangular box, Chinese brand front lifting cylinder, with integral fender, headlight cover.
Dimensions in mm	Front wheel track (mm): 2022 Rear wheel track (mm):1830 Overhang(front/rear) (mm):1500/1870 Overall Dimension (mm): 865025803450
Weight in kg	Dead weight (kg):13500 Gross vehicle weight (kg):25000

It seems you want more detailed information about dump trucks. Here’s an in-depth look:

Types of Dump Trucks

Standard Dump Truck:
- Description: Features a full truck chassis with a mounted bed. The bed is lifted using a hydraulic ram located between the cab and the bed.
- Uses: Suitable for general construction and hauling tasks.
- Advantages: Good maneuverability, versatile for many types of loads.
- Disadvantages: Limited load capacity compared to other types.
Articulated Dump Truck (ADT):
- Description: Has a hinge between the cab and the bed, allowing for greater flexibility and maneuverability on rough terrain.
- Uses: Primarily used in mining and heavy construction projects where off-road conditions are common.
- Advantages: Excellent off-road performance, higher payload capacity.
- Disadvantages: Higher cost, complex maintenance.
Transfer Dump Truck:
- Description: Pulls a separate trailer with a movable cargo container. The truck itself can deposit its load, then return to retrieve the trailer load.
- Uses: Ideal for long hauls and projects requiring multiple loads.
- Advantages: Increased load capacity without the need for additional drivers.
- Disadvantages: Complex operation, requires more space for maneuvering.
Side Dump Truck:
- Description: Features a tilting body that dumps material to the side instead of the rear.
- Uses: Useful in conditions where rear dumping is impractical, such as on narrow job sites.
- Advantages: Stability during dumping, less prone to tipping over.
- Disadvantages: Limited load directionality, not as versatile for all job sites.
Superdump Truck:
- Description: An extended truck with additional axles for increased load capacity. The extra axles can be lifted when the truck is empty or lightly loaded.
- Uses: Ideal for transporting large loads over longer distances, often used in road construction.
- Advantages: Higher payloads while maintaining road regulations.
- Disadvantages: Higher operational costs, requires specialized maintenance.
