China International 8*4 Commercial Howo Dump Truck 50 Tons Loading Big Horsepower for sale

International 8*4 Commercial Howo Dump Truck 50 Tons Loading Big Horsepower

Price Negotiable

Price: USD 41500-43000PER UNIT

MOQ: 1UNIT Dump Truck

Delivery Time: 30 WORKING DAYS

Brand: SINOTRUK HOWO DumpTruck

Product Description

SINOTRUK 50 Tons Loading Heavy Duty Dump Truck 8*4 Tipper Truck For Construction

Dump Truck Application

Dump truck is the vehicle that unloads cargo by hydraulic or mechanical lift.
Can be divided into backward tilting and lateral tilting.
Loading, downloading and transport earthwork, gravel and bulk materials.
Dump trucks often work with excavators, loaders, pavers, belt conveyors and other construction machinery.
Common drive types of dump trucks usually have 4*2, 6*4, 8*4 and so on.

Dump Truck Advantage Of HOWO DUMP TRUCK

Big horsepower, you can load more goods, and climb the slope without worry.
Robust and durable, saving maintenance costs and longer vehicle life.
The reinforced chassis and the reinforced cargo box are available. It makes the vehicle stronger and carry more. If loading the ore, the vehicle will be more wear-resistant.
Original spare parts worth $500 will be sent following trucks , including maintenance parts and consumables.
Fast delivery time, we can arange production according to your needs exactly and quickly
professional import and export dealing precedure, make customs clearance more high efficiency

Simple, easy operation and automotive style comfort along with combined service points and extended service

intervals means more focus on the work to be done, more time on the job, less time and money spent on servicing.

Dump Truck Technical Parameters

Vehicle series		HOWO 8x4 Tipper Dump Truck
Cab		HW76
Engine	Model	WD615 / D10
	Power(Ps/rpm)	336PS-380PS
	Maximum torque(Nm/rpm)	1340-1590NM
	Displacement(L)	9.726
Transmission		SINOTRUK HW series 10 gears Transmission,Transmission with main and auxiliary transmission structure, , main transmission with double counter shaft ,auxiliary transmission with planetary reduction. with PTO, HW19710 / HW19710T
Clutch		Φ430diaphragm spring Clutch,Hydraulic control air assisted. WD615.95Cstandard430B ,WD61596Cstandard430A
Front axle		HF9 drum-type, rated load of 9t
Rear axle		HC16 double reduction (central reduction+wheel reduction),speed ratio:5.73,4.8
Steering system		ZF8118 steering gear, ZF steering oil pump, system pressure 18MPa
Suspension	Steer Axle	front and rear leaf spring suspension, front suspension with shock absorber,transverse stabilizer
Suspension	Drive Axle	front and rear leaf spring suspension,rear suspension is disconnected type with transverse stabilizer.
Braking system	Service brake	dual-circuit air pressure brake
	Parking Brake	spring storage energy without air
	Auxiliary brake	Engine exhaust braking. standard Engine EVB,ABS, optional auto clearance adjusting arm.
Electric system	Voltage	24V
	Generator	2240W
	Batteries	12V/165Ah,2 pieces
	Starter Power	7.5kW
Wheels & Tyres	Tyres	12.00R20
Wheels & Tyres	Optional	12.00R24,12.00-24
Fuel Tank	Capacity	300 Liter
Weights (kg)	Curb weight(vehicle/chassis)	14830/10080;15130/10150;15200/10200;15200/10460
	Gross Vehicle Weight	31000
	Rated load	15670~16040
Vehicle Dimensions (mm)	Overall length x Overall width x Overall height	(9445~11350)×2496×(3237~3633)
	Wheelbase	1800+(3000~4600)+1350
	Front/rear overhang(vehicle/chassis)	1500/(1795/750);1500/(1895/920);1500/(2095/935);1500/(2100/1065)
	Wheel track of front axle	2041
	Wheel track of rear axle	1830
Performance	Maximum speed(km/h)	79/83
	Maximum gradeability(%)	20
	Minimum turning diameter(m)	<24
