China 336hp Sinotruk Howo7 10m3 8m3 Concrete Mixer Tank 6x4 Lhd White Color for sale

336hp Sinotruk Howo7 10m3 8m3 Concrete Mixer Tank 6x4 Lhd White Color

Name: 336hp Sinotruk Howo7 10m3 8m3 Concrete Mixer Tank 6x4 Lhd White Color
Brand: Jinan Heavy Truck Import & Export Co., Ltd.

Price Negotiable

Price: Negotiable

MOQ: 1unit

Delivery Time: 30days

Brand: Sinotruk

Product Description

Description

Concrete Mixer Truck 10CBM SINOTRUK HOWO 336HP 6X4 LHD ZZ5255GJBN3846B1

The Concrete Mixer Truck series of products produced by adopt Germany's proprietary technology.

Products material requirements, the production process, acceptance criteria, all adopt the technology

provided by the German standards.

This products use the imported reducer, motor and hydraulic pump. Dynamic force output by the second class chassis full power take off through the shaft power to the hydraulic pump, hydraulic pump produces hydraulic energy through tubing to the hydraulic motor, hydraulic motor to convert hydraulic energy into kinetic energy and through reducer then reduce and increase twist to the mixing tank, by adjusting the (double acting variable) servo controller of hydraulic pump Angle so as to realize controlling turning and speed of mixing drum, then to realize the concrete charging, stir and discharging operation.

Product Name	SINOTRUK HOWO 6X4 Mixer Truck
Chassis Model	ZZ1257N3647W
Driving Type	LHD (RHD is optional)
Cabin	HW76 cab, with one sleeper and two seats, 2-arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn,air conditioner , with transverse stabilizer,with 4-point support fully floating suspension + shock absorber.
Engine	Make: SINOTRUK Diesel 4-stroke direct injection diesel engine Engine model: WD615.69, Euro 2, 336 HP 6-cylinder in-line with water cooling, turbo-charging and intercooling Displacement: 9.726 L
Transmission	HW19710, 10F & 2R, with PTO Ratio: 14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Steering	ZF power steering, modol ZF8118, hydraulic steering with power assitance
Front Axle	HF9,1x9000 KGS Steering with doubleT-cross section beam
Rear Axle	HC16, 2x16000 KGS Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles. Ratio:5.73
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Chassis	Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer
Brake	Service brake: dual circuit compressed air brake Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels Auxiliary brake: engine exhaust brake
Electrics	Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tyres	295/80R22.5, tubeless tyres with one spare tyre
Fuel Tank	300L
Mixer Body	Tank Body: 8 Cubic Meters Mixer Pump: Eton (USA Brand) Motor: Eton (USA Brand) Speed Reducer: Bonfiglioli (Italy Brand)
Overall Dimension	900025503950 mm
