Welding Fume Purifier With 1500m3/H Large Air Flow Dust Collector 1.5kW
Welding Fume Purifier With 1500m3/H Large Air Flow Dust Collector 1.5kW
Fume Extractor Product Introduction
Welding fume extractor is suitable for manual welding and small workpiece welding. It also uses in simple laser welding, engraving and new material processing, ect. It is very flexible using in most working area, especially when the work position is very dispersive.
Technical parameters
| No. | Item | KSJ-1.5B | KSJ-1.5S2 |
| 1 | Fan type | centrifugal fan | centrifugal fan |
| 2 | Treatment of air flow | 1500±100 m3/h | 1800±100 m3/h |
| 3 | Motor power | 1.5kW | 1.5kW |
| 4 | Power supply | 3*380V ~/50Hz | 3*380V ~/50Hz |
| 5 | Filtration area | 10m2 | 8 m2 |
| 6 | Number of filter cartridges | 1 piece | 1 piece |
| 7 | Filter medium | Polyester+PTFE | Polyester+PTFE |
| 8 | Filtration efficiency | >99.9% | >99.9% |
| 9 | Noise | ≤72±5dB(A) | ≤74±5dB(A) |
| 10 | Cleaning way | Semi-automatic cleaning | Manual Cleaning |
| 11 | One suction arm | Ø160mm*3m | Ø160mm*3m |
| 12 | Weight (excluding suction arm) | 154±5KG | 120±5KG |
| 13 | Dimensions(excluding suction arm) | 550×550×1165mm | 550×550×1165mm |
Features
1.Mobile welding fume extractor has two directional and two rotary polyurethane casters with brack device for easy moving and stationing.
2 .Suction arm can be rotated by 360° and can reach the position flexibly and easily by pulling the handle on the hood and position in the absence of external force.
3 .The utility model has the advantages of low noise, stable performance, convenient operation and use, etc.
4. As the filtering precision of the main flter cartridge reaches the indoor emission standard the filtered cleaning air can be directly discharged indoor via the vent in the bottom of the extractor.
5. The filter inside makes use of semi-automatically rotating blowing system for cleaning ash while connecting the compressed air source, it makes the surface of tilter more clean and tidy.
6. It is suitable for the purification of fume and dust generated in all kinds of wlding, grinding and other places as well as for collecting rare metal particles and precious material.
Package & Shipping
Package: Package Used Wooden Box without Fumigation
The package would include spare parts box and machine installation tools.
Transportation By Sea or By Air are both Acceptable.
FAQ
Q1:Are you trading company or factory?
A1:We are professional factory for making metal welding, cutting fume extractor system and grinding dust collector system since 2007.
Q2:Do you have any certificates for your products and factory?
A2:Yes. We have kinds of certificates for different products. For example, CE, EMC,ATEX etc. Meanwhile our factory also is approved by ISO9001, 140001,OHSAS and EJ9001(Nuclear Industry).
Q3:Do you only sell products in name of your own brand?
A4:Generally it is 5-10 days if we have goods in stock, and it will be about 20-30 days if we don't have stock.It also depends on the quantity and technology request of order.
Q5:How do you package the goods?
Q6:How long is the warranty period of your dust collector?
A6:We provide free service (Expect filter cartridge) within 24 months and paid service for the whole working life.
Company Introduction
Shanghai Kaisen Environmental Technology Co., Ltd is established in 2007, it located at the technology innovation corridor of G60 in Shanghai. The factory area is about 6 0 0 0 square meter, and it also passed I S O 9 0 0 1, I S O 1 4 0 0 1 and O S A S 1 8 0 0 1 management certification. Over many years, we have been always committed to designing, research & development and manufacturing of industrial fume extractor system. These products are extensively applied to the processing of welding, cutting, grinding, painting, casting, chemical, wood, paper, food and other industries.
