Mobile Smoke Absorber Industrial Workshop Air Cleaning Equipment KSZ-1.5S
Mobile Smoke Absorber Industrial Workshop Air Cleaning Equipment KSZ-1.5S
Mobile Fume Extractor Product Introduction
Mobile welding fume extractor equipment is mainly used for welding, polishing, grinding, cutting and other metal process workshop. It has high work efficiency, and has the effect of purification for work environment. It is suitable for the work station where the dust removal is relatively dispersed and the amount of smoke is small.Welding fume extractor can improve the work environment effectively, ensure the workers health.
Technical parameters
| No. | Item | KSZ-1.5S | KSZ-1.5S1/S2 |
| 1 | Fan type | centrifugal fan | centrifugal fan |
| 2 | Fan air flow | 3000±100 m3/h | 3600±100 m3/h |
| 3 | Treatment of air flow | 1500 m3/h | 2000 m3/h |
| 4 | Motor power | 1.5 kW | 2.2kW |
| 5 | Power supply | 3*380V/50Hz or 3*220V/60Hz | 3*380V/50Hz or 3*220V/60Hz |
| 6 | Filtration area | 10m2 | 10m2 |
| 7 | Number of filter cartridge | 1 piece | 1 piece |
| 8 | Filter medium | PTFE coated filter element | Polyester+PTFE |
| 9 | Filtration efficiency | >99.99% | >99.99% |
| 10 | Solenoid valve | 1 piece | 1 piece |
| 11 | Compressed air | 5～6 bar | 5～6 bar |
| 12 | Compressed air volume | 25L | 25L |
| 13 | Noise | ≤72±5dB(A) | ≤74±5dB(A) |
| 14 | Weight | 210±5 kg | 215±10 kg |
| 15 | Dimensions(excluding suction arm) | 700×800×1600mm | 700×800×1600mm |
Welding Dust Collector Features
1. The dust collector consists of a centrifugal fan, a filter cartridge filter room, a pre-filter, a dust collection drawer, a purifier room body, a pulse cleaning system, an electric control device and a flexible suction arm with a dust hood.
2. Equipped with universal casters, can moved to any position of the workshop flexibility, and is not restricted by the unfixed dust point
3. Adopt high filtration precision imported PTFE coated filter material, the filtration efficiency for 0.3um dust can reach 99.9%. Low cost of consumabales, no need frequent replacement, saving environment protection.
4. 360° rotated suction arm, it can stay at any position. Depending on working condition, suitable suction hood and suction arm can be selected.
5. PLC control panel, easy to operate.
6. Automatic pulse cleaning system, keep the equipment constant suction volume and constant purification capacity.
7. Equipped with overcurrent and overload protection, safe and reliable.
Package & Shipping
Package: Package Used Wooden Box without Fumigation
The package would include spare parts box and machine installation tools.
Transportation By Sea or By Air are both Acceptable.
