KSDM-5.5-2 series integrated self-cleaning ventilation grinding table

Product introduction

1.The grinding table with downdraft and rear wall spark and air fume extraction is a clean and safe solution

    for industrial use.

2.The grinding process of the workpiece is usually essential in the welding shop. For the grinding of

    workpiece before and after welding work, this product uses the international advanced filtering

    technology; filtration efficiency reaches 99.9% for welding, cutting and grinding, ensuring high air flow at      the same time.

3. The grinding table is designed completely with user-friendly style, the design work and preparation

    of other accessories can be implemented based on actual customer needs, the side plate of the

    table is designed to open type and closed according to the characteristics of the workpiece,and

    it can also be designed to be lower ventilation or side ventilation according to the actual conditions.

    Kaisen has four types of grinding stations totally.

4. It also needs a grinding dust collector workbench with explosion-proof device for aluminum or

    alloy grinding process, we can provide the product them. And we have gained first explosion-proof

    inspection ertification in China.

Main features

1. CE and explosion-proof certification is available.

2. Worksize is 1890*855*650mm (LXWXH), the table is available in different sizes

3. Middle air flow, semi-automatically cleaning, maintaining easy.

4. Safe working due to robust material support

5. Side walls can be folded away so also suitable for larger workpieces

6. Comfortable to work with thanks to the ergonomically adapted sheet steel construction

Application: Industrial grinding of machined workpieces

Technical parameters
