Laser Cutting Machine Central Dust Collector for Laser Machine With Cartridge Filter

Product introduction

Central fume extractor is a series of products developed by our company based on the requirements of different site conditions. We can design the best fume & dust capturing device and piping system according to different site conditions, and choose suitable purification system according to air flow.

Design fume & dust capturing device according to the welded particle’s size, shape, welding position, welding craft, fume properties, site environment. We can provide various suction arms, fume suction nozzle, suction welding caps, suction welding torch etc. for common production. Welding rooms of different size and shape, manual / pneumatic / electric hood and the other kinds of dust capture device can also be designed for special sites need.

We can customize to design the device of dust caputuring according to the workpieces size, shape,

welding position,welding craft, welding fume nature, and on-site environment etc integrated factor. Also we provide the common mass production kinds of suction arm, suction nozzle,suctin welding cap, suction

welding guns etc. Meanwhile, to point some special requirement of work units, we also design the

different size welding house, manual/air/electric suction hood and the other types fume captureing device

The functionality of a filter lies in the filter element' s material, Kaisen's filter element is specially

developed for the purification of fume and fine particles generated in welding and cutting, solved thisindustry's problem of low filtration precision and filter element's blocking. And the outer surface

of the cartridge is covered by a layer of PTFE film layer through heat treatment a special

process.Cartridge wall is thin in structure and has high strength, and the surface film layer has a

very uniform pores, making a network structure with a bore diameter of 0.1 microns below.

Rotary dust blowing device is inserted inside the filter cartridge, and very close to the cartridge's inner  wall.When the solenoid valve opens, compressed air enter into two pipes drilled with nozzles,

implementing rotary blowing to clean every part of the filter cartridge. Compared with externally placed

blowing nozzles, rotary dust blowing "nozzles" blow force is even on every part of the cartridge, and have a thorough cleaning, avoid big noise and damage to the cartridge caused by instant huge blow impact of  the externally placed blowing method.

To the position polluted by a little oil mist, the company's special spray device not only dilutes oil mist

and prevents the dust from attaching to the filter surface to reduce its service life, but also plays a role in fire prevention.

Main features

1. CE certification is available.

2. Application for 4-6 welding units fume disposal, big plasma cutting fume disposal and robot welding

    housing fume disposal and so on.

3. It has adjustable air flow function though frequency converter.

4. Large air flow, automatically cleaning, maintaining easy, preprocessor to intercept the spark, filter

    quickly installation design.

5. Good parts make sure the qualilty, for example, Schneider,CHNT electrics, Siemens PLC and montoring

    screen, USA gas-pressure switch, Japan Toray filtering material, AKZO Nobel spraying powder etc.

Application

1. High levels of smoke and dust,

2. Traning centres and robotic welding lines,

3. Plasma and flame cutting systems,

4. Welding and grinding shops

Technical parameters
