Automatically Cleaning Laser Fume Extractor , Industrial Fume Extractor With Flexible Arm
Fume Exhaust, Industrial Laser Fume Extractor With Flexible Fume Extraction Arm
Product introduction
The product has the following advantages:
1. The product not only meets the standard of the state, but also meets the need of the actual working conditions. Product design requirements:
- Integrated design of the fan motor and filter system, making the structure compact and smaller size.
- The filter cartridge has long service life, stable performance, convenient replacement and large filter area.
- The total filter area of 30㎡, 3 filters.
- The operation control is easy to realize, the start and stop of the fan through the PLC and the touch screen, automatic cleaning button, the automatic cleaning of the dust on the surface of the filter should be realized.
- In addition, the pressure differential alarm indicator lamp and the power indicator lamp are also set up, making the whole operation simple and convenient.
2. The product should solve the feasibility and convenience of the field use. Easy to install and operate, repair and replace filter.
Main features
The dirty air is collected through the suction port and enters the filter. First layer is a steel baffle, changing the direction of air flow, the flow of gas flows into the filter chamber, which avoids to directly impact the filter. After filtering and separating through the filter cartridges with PTFE film, the clean air after filtering (expressed in blue) completes the whole process of filtering through the noise elimination to the outside. The dust particles separated by the filter cartridges with PTFE film fall into the dust container and collect the dust under the automatic cleaning function of the filter.
| No. | Item | Parameter |
| 1 | Fan type | centrifugal fan |
| 2 | Treatment of air flow | 2600±100 m3/h |
| 3 | Motor power | 1.5 kW |
| 4 | Power supply | 3×380 or 415V/50Hz |
| 5 | Filtration area | 30m2 |
| 6 | Number of cartridge filters | 3 pieces |
| 7 | Filter medium | PTFE coated filter element |
| 8 | Filtration efficiency | >99.9% |
| 9 | Solenoid valve | 3 pieces |
| 10 | Compressed air | 5～6 bar |
| 11 | Ash hopper volume |
10 L |
| 12 | Noise | ≤75±5dB(A) |
| 13 | Weight | 235±10kg |
| 14 | Dimensions(excluding suction arm) | 720(L)×700(W)×1745(H)mm |
Company Profile
Shanghai Kaisen Environmental Technology Co., Ltd has been always committed to designing, R&D and manufacturing of industrial dust collectors. Since 2007 we had been engaged in dust collectors for ten years. Our products are extensively applied to the processing of welding, cutting, grinding, painting, casting, chemical, wood processing, paper and other industries.
All of products are certificated by CE, meanwhile we have been exported around the world, for example Japan, UK, Chile, Australia, New Zealand and Vietnam etc. We finished many big projects in domestic market for famous enterprises such as CATERPILLAR (Xuzhou) INC, Buhler (Changzhou) Machinery Co., Ltd., BMW Automobile, Thyssen Krupp elevator, SIEMENS VAI, SANNY Heavy Industry etc.
