Large Air Flow Downdraft Grinding Table High Efficiency Maintaining Easy
7.5kW 8000 m³/h Air Flow 2140 mm Working Width Grinding Dust Extraction System
Functions introduction
The grinding table with downdraft and rear wall spark and air fume extraction is a clean and safe
solution for workshop.
It also needs a grinding dust collector workbench with explosion-proof device for aluminum or
alloy grinding process, we can provide the product them.
The grinding process of the workpiece is usually essential in the welding shop. For the grinding
of workpiece before and after welding work, this product uses the international advanced
filtering technology. Filtration efficiency reaches 99.9% for welding, cutting and grinding, ensuring
high air flow at the same time
The grinding table is designed completely with user-friendly style, the design work and preparation
of other accessories can be implemented based on actual customer needs, the side plate of the table
is designed to open type and closed according to the characteristics of the workpiece,and it can also
be designed to be lower ventilation or side ventilation according to the actual conditions.
Main features
1. CE and explosion-proof certification is available.
2. Large air flow, automatically cleaning, maintaining easy.
3. It has the light lamp and socket, it is easy to operate.
4. Side walls can be folded away so also suitable for larger workpieces
5. Comfortable to work with thanks to the ergonomically adapted sheet steel construction
6. We will customize the machine according to client requirement.
Technical parameters
| No. | Item | Parameter |
| 1 | Fan type | centrifugal fan |
| 2 | Treatment of air flow | 8000±100 m3/h |
| 3 | Motor power | 7.5 kW |
| 4 | Power supply | 3×380 or 415V/50Hz |
| 5 | Filtration area | 48 m2 |
| 6 | Number of cartridge filters | 4 pieces |
| 7 | Filter medium | Nanometer fiber element |
| 8 | Filtration efficiency | >99.9% |
| 9 | Solenoid valve3 | 4 pieces |
| 10 | Compressed air | 5～6 bar |
| 11 | Ash hopper volume | 50L |
| 12 | Noise | ≤72±5dB(A) |
| 13 | Weight | 1350±20kg |
| 14 | Dimensions |
2200(L)×1820(W)×1970(H)mm |
