5.5/7.5kW 4500-6800 m³/h Air Flow Central Welding And Cutting Fume Filtration System

Function introduction

1. Central Control system implements real-time monitoring and analysis on a number of important
    parameter of equipments in the operation and show them in the display, and it has self-diagnosis
    function, showing abnormal and error conditions in the operation of the equipment automatically.
    The central dust & fume purification system's performance is controlled by PLC controlling system.

2. Central fume&dust purifier is a series product researched, developed and designed by the company
    based on the requirements of different site conditions.The structure of integrated units is designed to
    compact and reasonable. A complete series of specifications has been developed to meet the on-site
    different work-in-conditions, whether large-scale welding or grinding shop, or welding centers, robotic
    welding production lines, plasma, or laser cutting blanking production lines, you can find suitable
    product model.

3. The functionality of a filter lies in the filter element’s material, Kaisen's filter element is specially
    developed for the purification of fume and fine particles generated in welding and cutting, solved this
    industry's problem of low filtration precision and filter element’s blocking. And the outer surface of
    the cartridge is covered by a layer of PTFE film layer through heat treatment a special
    process.

4. Rotary dust blowing device is inserted inside the filter cartridge, and very close to the cartridge's inner
    wall. When the solenoid valve opens, compressed air enter into two pipes drilled with nozzles,
    implementing rotary blowing to clean every part of the filter cartridge.

5. To the position polluted by a little oil mist, the company's special spray device not only dilutes oil mist
    and prevents the dust from attaching to the filter surface to reduce its service life, but also plays a role
    in fire prevention.

Main features

1. CE certification is available.

2. Application for small or medium plasma cutting fume disposal, under 3Kw laser cutting fume disposal.

3. Large air flow, automatically cleaning, maintaining easy, preprocessor to intercept the spark.

4. Good parts make sure the qualilty, for example,  Siemens PLC and montoring screen, Japan Toray filtering
    material, AKZO Nobel spraying powder etc.

Technical parameters
