1.5kw And 150 Mm Inlet Laser Fume Extractor Machine Welding And Cutting Dust Collector

1.5Kw And 150 Mm Inlet Laser Fume Extractor Machine Welding And Cutting Dust Collector

Main features
1. CE,ISO,ROHS certification is available.
2. The large filtering area is supplied according to the laser cutting fume feature.
3. Application for 1500x3000mm size table laser cutting fume and dust disposal.
4. Large air flow, automatically cleaning, maintaining easy, small dimension.
5. It is also suitable for plastic material cutting after changing filter material and increasing carbon active filter.

Product introduction
The laser fume extractor’s operation is controlled by PLC control system. All of operations control and information display are on the control panel with control button and display screen, the operation screen is humanization design and the operating is very convenient.

Our engineers can set the running program according to the requirement of different working conditions, for instance the automatically cleaning times after starting and stopping the equipment. Setting up the reverse blow cleaning’s technical parameters according to the on-site air environment, fume & dust characters and compressed air supplying.

It’s equipped with automatic shutdown mechanism when the temperature is too high (optional).

On the control panel, it includes:
- Power switch
- Power indicating light
- PLC implementation of filter automatically cleaning
- Fan rotation direction monitor (Inside the control box)

Technical Parameters
