Mobile High Vacuum Fume Extractor Welding And Cutting Electric Power Source
Price:
Negotiation
MOQ:
1 set
Delivery Time:
20 work days
Brand:
KAISEN
Product Description
1.5KW welding and cutting mobile high vacuum fume extractor used in robot machine
Main advantages
1. It is suitable for the welding occassion of frequently changing.
2. Professional solving the robot welding fume issue with the special suction nozzule.
3. DN51 or DN44 mm hose is available, it is easy to move and install in the process of using.
4. High efficiency vacuum pressure fan makes sure the usage life and suction force & air flow.
5. There is smart full automatically cleaning type with 2-3 suction nozzules model for optional.
6. The power is available from 1.1kw to 20 Kw (1.1,1.5,2.2,3.3,3.4,5.5/7.5/9/11/13/20 Kw), it will different requirements.
7. The structure of design is reasonable, the size is small and low noise with large suction force .
Working principle
The fume extractor has two stages filtering, first stage filtering is filtered of large particle spark, second stage is filtered of tiny dust.
This extractor is the preferred equipment for industry processing, welding, cutting and grinding dust disposal etc.
Application
Robot welding dust collection(this is a large number of applications case), large work piece splicing mobile welding, narrow space welding dust removal, mobile polishing dust removal. Other welding conditions which are not suitable for suction arm and pipe installation. The fume capturing efficiency reach 50%-90% according to different conditions.
Technical parameters
| Model | KSG-1.0A | KSG-1.5A | KSG-2.2A | KSG-3.3A |
| air flow | 180 (m3/h) | 195 (m3/h) | 372 (m3/h) | 675 (m3/h) |
| Motor Power | 1.0 (kw) | 1.5 (kw) | 2.2 (kw) | 3.3 (kw) |
| Voltage | 220V/50 Hz | 3x380V/50 Hz | 3x380V/50 Hz | 220V/50 Hz |
| Filtering area | 8 (m2) | 8 (m2) | 8 (m2) | 20(m2) |
| Surface Cleaning Methods | Change filter cartridge | Automatic Cleaning | Automatic Cleaning | Automatic Cleaning |
| Max Pressure | 16000-25000 (Pa) | 23000-29500 (Pa) | 27000 (Pa) | 16000-25000 (Pa) |
| Filtration Efficiency | >99.9% | >99.9% | >99.9% | >99.9% |
| Dusting interface | 1 pc (φ44 mm) | 1 pc (φ51 mm) | 2 pcs (φ44 mm) | 4 pcs (φ44 mm) |
| Noise | ≤72 dB(A) | ≤65 dB(A) | ≤70 dB(A) | ≤74 dB(A) |
| Demission | 580×445×920 (mm) | 550×650×1110 (mm) | 600×695×1200 (mm) | 650×820×1420 (mm) |
| Weight | 60 ±3(kg) | 107 ±5(kg) | 156 ±5(kg) | 205 ±10(kg) |
Package & Shipping
Package: Package Used Wooden Box without Fumigation
The package would include spare parts box and machine installation tools.
Transportation By Sea or By Air are both Acceptable.
