Industrial High Vacuum Extraction Laser Cutting Dust Collector With Pre Filter System 300m3/H
Price:
Negotiation
MOQ:
1 set
Delivery Time:
20 work days
Brand:
KAISEN
Product Description
2.2KW Industry Laser Cutting Dust Collector With Pre-filter System 300m3/h
Working principle
The fume extractor has two stages filtering, first stage filtering is filtered of large particle spark, second stage is filtered of tiny dust.
This extractor is the preferred equipment for industry processing, welding, cutting and grinding dust disposal etc.
Product introduction
The extractor has front connector and can be connected to various professional suction connectors, suction welding guns or breathing masks through a hose of Φ44(51)mm; by connecting with hose of Φ44(51)mm and professional nozzle, it also can be used in robot and welding machine’s fume purification. The nozzle is fixed on the welding gun and moves with the welding gun to suck welding smoke simultaneously; also be used in the welding test and in the cleaning of the training sites.
On the control panel, it includes:
- Power Switch
- Fan Switch
- Power indicating light
- Semi-automatic cleaning
Application
Robot welding dust collection(this is a large number of applications case), large work piece splicing mobile welding, narrow space welding dust removal, mobile polishing dust removal. Other welding conditions which are not suitable for suction arm and pipe installation. The fume capturing efficiency reach 50%-90% according to different conditions.
Technical parameters
| Model | KSG-1.0A | KSG-1.5A | KSG-2.2A | KSG-3.3A |
| air flow | 180 (m3/h) | 195 (m3/h) | 372 (m3/h) | 675 (m3/h) |
| Motor Power | 1.0 (kw) | 1.5 (kw) | 2.2 (kw) | 3.3 (kw) |
| Voltage | 220V/50 Hz | 3x380V/50 Hz | 3x380V/50 Hz | 220V/50 Hz |
| Filtering area | 8 (m2) | 8 (m2) | 8 (m2) | 20(m2) |
| Surface Cleaning Methods | Change filter cartridge | Automatic Cleaning | Automatic Cleaning | Automatic Cleaning |
| Max Pressure | 16000-25000 (Pa) | 23000-29500 (Pa) | 27000 (Pa) | 16000-25000 (Pa) |
| Filtration Efficiency | >99.9% | >99.9% | >99.9% | >99.9% |
| Dusting interface | 1 pc (φ44 mm) | 1 pc (φ51 mm) | 2 pcs (φ44 mm) | 4 pcs (φ44 mm) |
| Noise | ≤72 dB(A) | ≤65 dB(A) | ≤70 dB(A) | ≤74 dB(A) |
| Demission | 580×445×920 (mm) | 550×650×1110 (mm) | 600×695×1200 (mm) | 650×820×1420 (mm) |
| Weight | 60 ±3(kg) | 107 ±5(kg) | 156 ±5(kg) | 205 ±10(kg) |
Package & Shipping
Package: Package Used Wooden Box without Fumigation
The package would include spare parts box and machine installation tools.
Transportation By Sea or By Air are both Acceptable.
