Flame Retardant Industrial Air Cleaner Mobile Welding Series Fume Extractor
KAISEN Industrial Air Cleaner KSJ-0.7S Mobile Welding Series Fume Extractor
Standard Parameters
| No. | Item | Parameter |
| 1 | Fan type | centrifugal fan |
| 2 | Treatment of air flow | 1000±100 m3/h |
| 3 | Motor power | 0.75kW |
| 4 | Power supply | 220-240V ~/50Hz |
| 5 | Filtration area | 20 m2 |
| 6 | Number of filter cartridges | 1 piece |
| 7 | Filter medium | Synthetic wood pulp fiber filter paper |
| 8 | Filtration efficiency | >99.9% |
| 9 | Noise | ≤74±5dB(A) |
| 10 | Ash hopper volume | 2 L |
| 11 | One suction arm | Ø160mm*2m |
| 12 | Weight (excluding suction arm) | 98±5KG |
| 13 | Dimensions(excluding suction arm) | 510×610×990mm |
production information
What we provide
KAISEN produces a wide range industrial fume/dust extraction and collection equipments, such as mobile welding fume extractor,laser fume/dust collector,soldering fume extractor, mobile high vacuum fume extractor,central high vacuum fume extractor,self-circulation purifying tower,plasma cutting valve-type fume extraction system,central/downdraft grinding dust collector...etc. and other spare parts included.
Package & Shipping
Package: Package Used Wooden Box without Fumigation
The package would include spare parts box and machine installation tools.
Transportation By Sea or By Air are both Acceptable.
