2.2kW Industrial Fume Extractor Collector Laser Cutting Dust Collection System Air Flow 2600 m³/h

Working Principle

The fume comes from the processing will be sucked into the extractor through the hood, first the fume passes the 1st layer preventer plate which will ramify the fume to avoid residual sparks enter into filter layer directly. Finally, the fume enters the second layer of HEPA filter cartridge for ultimate purification, and HEPA' s filtration efficiency can reach 99.9%. As the filtering precision of the main filter cartridge reaches the indoor emission standard, the filtered clean air can be directly discharged indoor via the vent in the bottom of the extractor.

Feature

1. The laser fume extractor's operation is controlled by PLC control system.

2 .All of operations control and information display are on the control panel with control button and display screen, the operation screen is humanization design and the operating is very convenient.

3. Our engineers can set the running program according to the requirement of different working conditions, for instance the automatically cleaning ash times after starting and stopping the equipment.

4. Its filtration efficiency can reach 99.9%.

5. Setting up the reverse blow cleaning's technical parameters according to the on-site air environment, fume & dust characters and compressed air supplying.

6. The controlling system implements real time monitoring and analyzes on a number of important parameters of the equipment in operation, and show them on the display screen.

7. It's equipped with automatic shutdown mechanism when the temperature is too high (optional) and automatically rotating blowing protection when the pressure difference is too high (optional).

On the control panel, it includes:

-Power switch

-Power indicating light

-PLC implementation of filter semi-automatically cleaning

-Fan rotation direction monitor(Inside the control box)

Parameters

KSJ-2.2G
