Polyester Filter 7.5kW Central Welding Fume Extractor
KAISEN Commercial Industrial Central Dust Collector
Technical Parameters
| Kaisen Economical Dust Extraction System Cetralized Fume Extractor KSDC-8604A1 | ||
| 1 | Fan type | centrifugal fan |
| 2 | Treatment of air flow | 6800±100 m3/h |
| 3 | Motor power | 7.5kW |
| 4 | Power supply | 3×380 or 460V/50Hz |
| 5 | Filtration area | 60m2 |
| 6 | Number of cartridge filters | 4 pieces |
| 7 | Filter medium | PTFE coated filter element |
| 8 | Filtration efficiency | >99.9% |
| 9 | Solenoid valve | 4 pieces |
| 10 | Compressed air | 5～6 bar |
| 11 | Ash hopper volume | 25L |
| 12 | Noise | ≤72±5dB(A) |
| 13 | Weight | 750±20kg |
| 14 | Dimensions(excluding suction arm) | 1100(L)×1100(W)×2750(H)mm |
How can welding fumes affect your health?
Exposure to different types of welding fumes produce different health effects. If over the years you breathe in gases, fumes, and vapors in large quantities, your health will suffer.
Shortness of breath
Bronchitis
Fluid in the lungs (edema)
Inflammation of the lungs (pneumonia)
Loss of appetite
Coughing ,Irritation of the eyes, nose, and chest
Cramps
Nausea / vomiting, fluid in the lungs (edema)
Some short-term health effects are:
Chronic lung problems (bronchitis, pneumonia, asthma, emphysema, silicosis,
Lung cancer
Cancer of the larynx
Cancer of the urinary tract
Other health problems that may be related to welding fumes are:
Skin diseases & Damages
Hearing loss
Gastritis, ulcers of the stomach
Kidney damage
Heart disease
KAISEN design manufacturing Welding Fume Extractor machines in various filtration capacity. Our machine purify the hazardous welding fume up-to 99 % and circulate the pure air. We are supplying flexible extraction arm 3meter length for easy capture for fumes.
Welding Fume Extractor :-
Welding Fume Extractor with articulated suction arm to collect dust particles and fumes from various kind of welding process. CLEANTEK Welding Fume Extractor are manufactured as per the accepted quality standards. High volume Extraction done by using suction arm with suction blower threw electrostatic filter ( 3 stage Filter ) assures good health and safety for human resources by removing welding smoke. Additionally, Welding Fume Extractor keeps product and production machines dust contaminant free. We give the time delivery of Welding Fume Extractor at given time frame.
