Dia 200mm Welding Smoke Extractor

Price Negotiable

Price: Negotiation

MOQ: 1 set

Delivery Time: 30 days

Brand: KAISEN

Product Description

The Suction Diameter Is 200mm Intelligent Industrial Dust Collector Equipped With Siemens Motor And Screen

Introduction

Mobile intelligent welding fume extractor has two directional and two rotary polyurethane casters with brake device for easy moving and stationing. It is suitable for the purification of fume and dust generated in all kinds of welding, grinding and other places as well as for collecting rare metal particles and precious material.

Suction arm can be rotated by 360 °and can reach the position flexibly and easily by pulling the handle on the hood and position in the absence of external force. Depending on needs, 2m, 3m flexible suction arm are available. Suction arm uses high temperature resistant, flame retardant and wearable composite material, it will not crack after burning through by spark and has a longer usage life. The diameter of suction arm is 160mm.It's equipped with automatic shutdown mechanism when the temperature is too high (optional).

On the control panel, it includes:
- Power switch
- Power indicating light
- PLC implementation of filter automatically cleaning
- Fan rotation direction monitor (Inside the control box)

Working principle

Separation: Dust laden fume are sucked into the extractor by the suction force induced by fan’s working, with deflector fume’s flowing speed is slowed, big practical and sparks are cooled, separated and then settle into dust collector. Fine fume and dust enter into filter compartment to be filtered by the filter cartridge. The filter cartridge is coated with PTFE film which is covered with uniform pores, it has good air permeability, and dusts are filtered out on its surface. Purified air enters into the filter cartridge’s interior and then discharged into workshop directly or out of the workshop through pipe line.

Cleaning: When dusts accumulate continuously on filter cartridge’s surface, the pressure difference between its interior and exterior will increase steadily, when the pressure difference reach pre-set value(1500Pa), the pulse valve will open, dry, oil-free compressed air rush into the reverse blow cleaning system. The system rotate and high pressure air stream jet at the interior of filter cartridge, blow off dusts accumulated on the filter cartridge’s surface, dusts fall into dust collector under gravity, thus the whole cartridge’s surface is cleaned.

This extractor can be automatically cleaned and manually cleaned, automatically cleaning is as following:

1. When air pressure difference reach 1500Pa between the interior and exterior of the filter cartridge, the

system will implement interval rotation pulse blow cleaning.

2. When the fan stops working, the system will implement rotation pulse blow cleaning for three times.

Technique Data

Model	KSZ-1.5S	KSZ-1.5S1/S2	KSZ-3.0D	KSZ-3.0D1/D2
Fan Air Flow	3000 ± 100m³/h	3600 ± 100m³/h	4000 ± 100m³/h	4000 ± 100m³/h
Inlet Air Flow	1500m³/h	2000m³/h	2600m³/h	2800m³/h
Motor Power	1.5kW	2.2kW	3.0kW	3.0kW
Power Supply	3×380V/50Hz	3×380V/50Hz	3×380V/50Hz	3×380V/50Hz
Filter Material	Polyester + PTFE	Polyester + PTFE	Polyester + PTFE	Polyester + PTFE
Filtration Area	10㎡	10㎡	20㎡	20㎡
Filtration Efficiency	≥99.9%	≥99.9%	≥99.9%	≥99.9%
Filtration Precision	≥0.3μm	≥0.3μm	≥0.3μm	≥0.3μm
Filter Cartridge	1pc	1pc	2pcs	2pcs
Cleaning Method	Automatic	Automatic	Automatic	Automatic
Compressed Air	0.5~0.6MPa	0.5~0.6MPa	0.5~0.6MPa	0.5~0.6MPa
Noise Level	≤72 ± 5dB(A)	≤72 ± 5dB(A)	≤74 ± 5dB(A)	≤74± 5dB(A)
Dimension (W×D×H)	700×800×1600mm	700×800×1600mm	800×800×1633mm	800×800×1633mm
Weight	210 ± 5kg	215 ± 5kg	266 ±10kg	266 ± 10kg
