Industrial Intelligent Welding Fume Central Dust Collector With CE/RoHS Certificate

Introduce

Central fume extractor is a series of products developed by our company based on the requirements of different site conditions. We can design the best fume & dust capturing device and piping system according to different site conditions, and choose suitable purification system according to air flow.

120 series of central dust purifier, central combined 120 series dust purifier.

Central integrated unit structure design compact reasonable, human controllable, Not only has the advantage of high precision and high energy efficiency, Can also be based on the actual operating conditions of intelligent frequency conversion, Energy saving reliable; And the entire purification system is controlled by the roar C system, Real-time monitoring and analysis on the screen, Can also APP remote monitoring, Self-diagnostic, Intelligent system can ensure the long-term stable operation of the equipment.

Main Features

1. Central Control system implements real-time monitoring and analysis on a number of important parameter of equipments in the operation and show them in the display, and it has self-diagnosis function, showing abnormal and error conditions in the operation of the equipment automatically. The central dust & fume purification system’ s performance is controlled by PLCcontrolling system.

2. The functionality of a filter lies in the filter element’s material, Kaisen's filter element is specially developed for the purification of fume and fine particles generated in welding and cutting, solved this industry’s problem of low filtration precision and filter element’s blocking. And the outer surface of the cartridge is covered by a layer of PTFE film layer through heat treatment a special process. Cartridge wall is thin in structure and has high strength, and the surface film layer has a very uniform pores, making a network structure with a bore diameter of 0.1 microns below.

3. Rotary dust blowing device is inserted inside the filter cartridge, and very close to the cartridge’s inner wall. When the solenoid valve opens, compressed air enter into two pipes drilled with nozzles, implementing rotary blowing to clean every part of the filter cartridge. Compared with externally placed blowing nozzles, rotary dust blowing "nozzles" blow force is even on every part of the cartridge, and have a thorough cleaning, avoid big noise and damage to the cartridge caused by instant huge blow impact of the externally placed blowing method.

Technique Data

​​​​
