20KW Central Vacuum Welding Fume Extractor 2100mm3/H 45m2 Filtering
CE/RoHS Certificate Central Vacuum Welding Fume Extractor Connect The Stainless Steel Pipe
Work principle
The mobile high vacuum fume extractor has a reasonable design structure with light weight and strong suction. It has a built-in high-vacuum turbine fan unit. The light and compact body can be moved at will. With source capture, the high-pressure composite suction hose can be used flexibly to reach positions that cannot be reached by the suction arm and any other means.
In addition, it has a multi-station integrated design, compact structure, automatic frequency conversion, PLC automatic monitoring of working status. It is convenient to operate, energy-saving and reliable, and can be flexibly applied to various working conditions.
Introduction:
The mobile high vacuum fume extractor has a reasonable design structure with light weight and strong suction. It has a built-in high-vacuum turbine fan unit. The light and compact body can be moved at will. With source capture, the high-pressure composite suction hose can be used flexibly to reach positions that cannot be reached by the suction arm and any other means.
In addition, it has a multi-station integrated design, compact structure, automatic frequency conversion, PLC automatic monitoring of working status. It is convenient to operate, energy-saving and reliable, and can be flexibly applied to various working conditions.
Technical Data
|
Model |
KSG-09B |
KSG-09Ba |
KSG-11B |
KSG-13B |
KSG-20B |
|
Inlet Air Flow |
560±100 m3/h |
1200±100 m3/h |
900±100 m3/h |
1300±100 m3/h |
2100±100 m3/h |
|
Motor Power |
7.5kW |
9KW |
11KW |
13KW |
20KW |
|
Power Supply |
3x380V/50Hz |
3x380V/50Hz |
3x380V/50Hz |
3x380V/50Hz |
3x380V/50Hz |
|
Maximum Pressure |
29500Pa |
20000Pa |
28000Pa |
30500Pa |
26000Pa |
|
Filtration Material |
Polyester + PTFE |
Polyester + PTFE |
Polyester + PTFE |
Polyester + PTFE |
Polyester + PTFE |
|
Filtration Area |
15㎡ |
15㎡ |
15㎡ |
45㎡ |
45㎡ |
|
Filtration Efficiency |
≥99.9% |
≥99.9% |
≥99.9% |
≥99.9% |
≥99.9% |
|
Filtration Precision |
≥0.3um |
≥0.3um |
≥0.3um |
≥0.3um |
≥0.3um |
|
Filter Cartridge |
1 Pc |
1 Pc |
1 Pc |
3 Pcs |
3 Pcs |
|
Cleaning Method |
Automatic cleaning |
Automatic cleaning |
Automatic cleaning |
Automatic cleaning |
Automatic cleaning |
|
Compressed Air |
0.5~0.6Mpa |
0.5~0.6Mpa |
0.5~0.6Mpa |
0.5~0.6Mpa |
0.5~0.6Mpa |
|
Noise Level |
≤75±5 dB |
≤75±5 dB |
≤75±5 dB |
≤75±5 dB |
≤75±5 dB |
|
Dimension (WxDxH) |
1300×750×1900mm |
1300×750×1900mm |
1300×750×1900mm |
1750×958×2352mm |
1750×958×2352mm |
|
Weight |
735±35kg |
735±35kg |
735±35kg |
757±20kg |
810±20kg |
