Fume Extractor Product Introduction
Welding fume/smoke extractor is a moveable filtration system with internally installed filter and counter blowing device. It is the necessary equipment for metal processing to clean the welding fume and dust.
Technical parameters
| No. | Item | KSZ-3.0D | KSZ-3.0D1/D2 |
| 1 | Fan type | Centrifugal fan | Centrifugal fan |
| 2 | Treatment of air flow | 2600±100 m3/h | 2800±100 m3/h |
| 3 | Motor power | 3.0 kW | 3.0kW |
| 4 | Power supply | 3×380/50Hz or 3×220V/60Hz | 3×380/50Hz or 3×220V/60Hz |
| 5 | Filtration area | 20m2 | 20m2 |
| 6 | Number of cartridge filters | 2 pieces | 2 pieces |
| 7 | Filter medium | Polyester+PTFE | Polyester+PTFE |
| 8 | Filtration efficiency | >99.9% | >99.9% |
| 9 | Filtration Precision | ≥0.3um | ≥0.3um |
| 10 | Compressed air | 5～6 bar | 5～6 bar |
| 11 | Cleaning Way | Automatic Cleaning | Automatic Cleaning |
| 12 | Noise | ≤74±5dB(A) | ≤74±5dB(A) |
| 13 | Weight | 266±10kg | 266±10kg |
| 14 | Dimensions | 800(L)×800(W)×1633(H)mm | 800(L)×800(W)×1633(H)mm |
Working Principle
The fume comes from the processing will be sucked into the extractor through the hood, first the fume passes the 1st layer preventer plate which will ramify the fume to avoid residual sparks enter into filter layer directly. Finally, the fume enters the second layer of HEPA filter cartridge for ultimate purification, and HEPA' s filtration efficiency can reach 99.9%. As the filtering precision of the main filter cartridge reaches the indoor emission standard, the filtered clean air can be directly discharged indoor via the vent in the bottom of the extractor.
Features
1. High efficiency custom aluminum impeller
2. Polyester + PTFE filter material, 0.3 um filtration precision
3. 360° rotation suction arm, the length is 3 or 4 meters
4. Self-supporting & self-positioning suction hood
5. Special designed dust cleaning device, semi-auto & full-auto cleaning method
6. φ200mm suction arm, high temperature resistance & flame retardant & abrasion resistance
Package & Shipping
Package: Package Used Wooden Box
Transportation By Sea or By Air are both Acceptable.
