Anti Corrosive Epoxy Coating For Steel Pipe High Gloss RAL 1014 Ivory Color
RAL1014 ivory Pipe electrostatic Spray pure Epoxy Anticorrosive Powder Coating
Epoxy powder coating is a series of epoxy based powder coating designed to give optimum mechanical properties and exceptional protective qualities on components and fabrications where long term exposure to ultra violet light or exterior weathering is not anticipated. This series are available in a wide range of colors with different gloss and texture.
|
Product Details |
|
|
Type |
Epoxy Powder Coating |
|
Gloss Level |
Semi Gloss 90% |
|
Surface Finish |
Smooth |
|
Powder Property |
|
|
Appearance |
Fine powder |
|
Particle Size |
Average 32-40μm |
|
Specific Gravity |
1.3-1.5g/cm3 |
|
Coverage |
7-8 square meter per Kg at 80μm film thickness |
|
Powder Coated Film Mechanical Properties |
|
|
Adhesion |
Cross-cut (2mm), no loss of adhesion |
|
Impact Resistance |
Direct & Indirect 50kg/cm |
|
Pencil Hardness |
2H |
|
Flexibility |
7mm Mandrel |
|
Bending Test |
3mm |
|
Powder Coated Film Chemical Resistance |
|
|
Salt Spray Test |
5% NaCl Solution for 1000 hours - No change |
|
Acid Resistance |
5% HCL for 48 hours dip test - No change |
|
Alkali Resistance |
5% NaOH for 48 hours dip test - No change |
|
Surface Preparation |
|
|
All surfaces shall be degreased and pre-treated for optimal performance before application |
|
|
Aluminium |
Yellow chromate or green chromate/phosphate |
|
Ferrous metals |
Zinc phosphate or Iron phosphate |
|
Zinc coated metals |
Zinc phosphate or choromate conversion |
|
Storage Stability |
|
|
Store in ventilated, dry, clean room, temperature < 25℃ |
|
|
Relative humidity 50-65% |
|
|
Away from direct sunlight, fire, heat |
|
|
For best performance, use within 6 months |
|
