Metal Decorative Powder Coating PANTONG2727C Blue Color With ROHS Approval
Metal Decorative Powder Coating PANTONG2727C Blue color ROHS Approval
sometimes a powder coating is applied during a fluidized bed application. Preheated parts are dipped in a hopper of fluidizing powder and the coating melts, and flows out on the part. Post cure may be needed depending on the mass and temperature of the part and the type of powder used. No matter which application process is utilized, powder coatings are easy to use, environmentally friendly, cost effective, and tough!
We are committed to the technological advancement of metal and aluminum decoration systems, seeking improvements in image definition, longevity, and durability. TOPO offers superior technical service, training and efficient delivery of decoration supplies for customers.
|
SPECIFICATION |
||
|
Coating film technical data |
Curing conditions
|
180°C/20min, 190°C/15min, 200°C/10min
|
|
Impact resistance(drop hammer)
|
50kg.cm pass
|
|
|
Pencil hardness
|
H-2H
|
|
|
Gloss(60°gauge head)
|
High gloss type≥85% Semi gloss type:51-84% |
|
|
Adhesion(cross cut test)
|
1mm 6x6 0 grade
|
|
|
Bending test(tapering spindle)
|
3mm pass
|
|
|
Salt Spray Test
|
>500 hours
|
|
|
Humidity resistance
|
>1,000 hours
|
|
|
Application recommendation |
Application Voltage
|
60-80KV
|
|
Film Thickness
|
60-80 Micron
|
|
|
Average coverage
|
8-12 square meters/kg, thickness 60μm(100% of the powder coating utilization rate)
|
|
|
Storage
|
1 year. Store in ventilated, dry, clean room, temperature < 25℃, away from direct sunlight, rain, fire, heat.
|
|
