Industrial Pure Polyester TGIC FREE Powder Coating For Metal Finish
Industrial Pure Polyester TGIC FREE Powder Coating for Metal Finish
BRIEF INTRODUCTION
Electrostatic polyester powder coating gives an excellently homogenous surface. Due to a high level of production control, areas of thicker paint at the edges and corners or the 'orange peel' texture usually associated with powder coating are minimized. Electrostatic polyester powder coating is a more cost effective option than PVDF coatings but not as durable. Baked at low temperatures, it is an energy efficient coating technology suitable for interior and exterior applications. Large panels, curves and complex forms can be easily coated. UV stable and highly weather resistant, its performance can be tailored to meet the demands of particular applications and various degrees of gloss can be specified.
RANGE
High Gloss, Gloss, Semi Gloss & Matt
Fine Texture & Ripple
Antique Finishes and Tinted Lacquers
Metallic Effects
Sparkle Effects
Fluorescent Effects
ADVANTAGES
High solid content, excellent fullness of film
Thick coating is available
High sanding performance & good abrasion
High application efficiency & easy to apply
Primer can improve hardness of top coat & save the consumption of topcoat
SPECIFICATION
| Main Material | Polyester resin,barium sulfate,titanium dioxide |
| Surface Type | Gloss,matte,wrinkle,sandgrain,antique,Hammer,crocodile skin,wood effect,candy,chrome,transparent,semitransparent,metallic,and special pattern |
| Powder Properties | Specific gravity : 1.3 - 1.75 (depend on colors) |
| Average particle size : 35 - 45um | |
| Coating Properties | Film thickness(ISO 2178) :60 - 90 μm |
| Coverage:15m2 based on 60μm | |
| Pencil hardness: ASTM D3363,H-2H | |
| Adhesion :GB/T 9286-1998,0 grade | |
| Bending test:GB/T 6742 ,=<2mm | |
| Cupping test:GB/T 9753,>=7mm | |
| Direct and reverse impact (ASTM D2794) : > 50kg.cm | |
| Salt spray Resistance ( ASTM B117, 1000hrs)(Maximum undercutting ,1 mm ): No blistering or loss of adhesion | |
| Heat and moisture test GB/T 1740,>=1000 hours,no change | |
| Application Schedule | Applied by : Electrostatic spraying devices |
| Curing schedule :10 minutes at 200 ºC | |
| Advantage | Good adhesion,anti-corrosion,UV resistant, strong coating film, |
| Accurate colors, good leveling | |
| Shelf Life | 12 months |
STORAGE CONDITIONS
Temperature: ≤30ºC
Humidity Conditions: Dry, Cool and Ventilated
Storing Requirement: Cannot be piled up over 4 cartons;
Seal the PE bag after using;
Away from VOC, fire and heat;
Validity: 6 months (If the parameters are tested to be qualified, the product still can be used expire date)
