With Piston Rod Single Acting Dump Truck Hydraulic Oil Cylinder
With Piston Rod Single Acting Dump Truck Hydraulic Oil Cylinder
Dallast series of products, larger bore, lifting stronger.
Maximum working pressure M36PA, anti-high pressure capability.
After special treatment of high-quality, high-precision 27SIMN seamless steel pipe, higher yield strength, unified procurement by the company to ensure product quality as one.
Hinge up and down: the overall forging process.
New sealing structure: high quality international famous brand seals to ensure that the cylinder will not leak oil under high pressure and harsh conditions.
| Parker and Custom Hoists Kind 3 Stage | ||||
| Model No. | First Stage Diameter | Stroke | Closed Length | Open Length |
| 3TG F5*72 | 5" |
72" (1829mm) |
37.19" (945mm) |
109.19" (2773mm) |
| 3TG F5*84 | 5'' |
84" (2134mm) |
41.19" (1046mm) |
125.19" (3180mm) |
| 3TG F5*107 | 5" |
107.56" (2732mm) |
48.38" (1229mm) |
155.94" (3961mm) |
| 3TG F5*126 | 5" |
126.63" (3216mm) |
54.56" (1386mm) |
181.19" (4602mm) |
| 3TG F6*86 | 6" |
86.75" (2203mm) |
40.88" (1038mm) |
127.63" (3241mm) |
| 3TG F6*104 | 6" |
103.94" (2640mm) |
47" (1194mm) |
150.94" (3834mm) |
| 3TG F6*107 | 6" |
107.56" (2732mm) |
48.38" (1289mm) |
155.94" (3961mm) |
| 3TG F6*111 | 6'' |
111" (2819mm) |
49.94" (1268mm) |
160.94" (4087mm) |
| 3TG F6*120 | 6'' |
120" (3048mm) |
53.5" (1359mm) |
173.5" (4407mm) |
| 3TG F6*123 | 6'' |
123" (3124mm) |
54.94" (1395mm) |
177.94" (4519mm) |
| 3TG F6*126 | 6'' |
126.31" (3208mm) |
54.56" (1386mm) |
180.87" (4594mm) |
| 3TG F6*140 | 6'' |
140.25" (3562mm) |
59.81" (1519mm) |
200.06" (5081mm) |
Specification
Application: dump truck/tipprt/trailer/garbage truck
Designed For: Single/double-acting
Stage: 3~5 stage cylinder
Max inner tube diameter: 170mm,180mm,195mm,200mm,210mm,etc.
Mounting distance: 325mm/345mm/425mm
Working Pressure: 16Mpa
Stroke: 750mm~12000mm
Tipping Weight: 35~68Ton
Seal Type: Parker,NOK, BUSAK SHAMBAN or as customer's requirement
Piston Rod: Chrome or nickel plated,ground & polished piston rod
Tube: High tensile cold drawn tube, precision honed for extended seal life
| Type | Max | Min |
| Cylinder bore | 280 mm | 10 mm |
| Piston Rod Diameter | 280 mm | 10 mm |
| Retract Length | 3500 mm | 50 mm |
| Stretch Length(Single stage cylinder) | 6500 mm | 60 mm |
| Stretch Length(Dual stage cylinder) | 12500 mm | 60 mm |
| Working Pressure | 36MPa | 5Mpa |
| Bore size | 248mm | 85mm |
Any interesting or inquiry, please feel free to contact, if you can provide the following information with your quotation, we will be very appreciated and offer you ASAP. Thanks for your cooperation.
1. Hydraulic cylinder Data:
a. Bore size:
b. Stoke length:
c. Rod Diameter:
d. Mounting Type:
e. Mounting length:
d. paint color requirement:
2. Application Data:
a. Type of machine (loader, steer loader, excavator, etc.):
b. Type of function (hoist, swing, steering, etc.):
c. Type of structure (piston, telescopic):
d. Single acting or double acting
e. Operating Pressure:
