2/3/4 Stage Parker FC Type Single Acting Hydraulic Cylinder For Vehicles
2/3/4 Stage Parker FC Type Single Acting Sleeve Hydraulic Cylinder for Vehicles
The multistage telescopic hydraulic(FC FE FEE) is used for dump trucks, it is interchangeable with Holland's Hyva and Uk's Edbore.
| Max stroke | 12000mm | Maxpressure | 24Mpa |
| Max capacity | 120T | Bore size | 75-278mm |
| Heat Treatment | Quenching | Color | customization |
Product Description:
Dallast Hydraulic Cylinders, for Agricultural, Construction, and Mobile Equipment, are precision manufactured using only the finest materials. Choose to form our standard Double Acting cylinders or we will manufacture special cylinders to meet your requirements. Bore Sizes: 1 1/2- 6 inches 3,000 PSI Pressure Rated WARRANTY: Dallast guarantees its Hydraulic Cylinders, when properly installed within product specifications, for a period of 12 months from the date of shipment from the factory, against defects in the workmanship and/or materials only. We will, subject to inspection by factory authorized personnel, repair or replace any cylinder found to be defective. The sale of our products under any other warranty, implied or expressed, is not authorized by the factory.
Specification:
| Parker | Model No. | First Stage Diameter | Stroke(A) | Closed Length(B) | Open Length(C) |
| S53DC-66-72 | 3TG F5*72 | 5" 127 | 72"(1829mm) | 37.19" (945mm) | 109.19" (2773mm) |
| S53DC-66-84 | 3TG F5*84 | 5'' 127 | 84" (2134mm) | 41.19" (1046mm) | 125.19" (3180mm) |
| S53DC-65-107 | 3TG F5*107 | 5" 127 | 107.56" (2732mm) | 48.38" (1229mm) | 155.94" (3961mm) |
| S53DC-65-126 | 3TG F5*126 | 5" 127 | 126.63" (3216mm) | 54.56" (1386mm) | 181.19" (4602mm) |
| S63DC-101-86 | 3TG F6*86 | 6" 152.4 | 86.75" (2203mm) | 40.88" (1038mm) | 127.63" (3241mm) |
| S63DC-101-104 | 3TG F6*104 | 6" 152.4 | 103.94" (2640mm) | 47" (1194mm) | 150.94" (3834mm) |
| S63DC-101-107 | 3TG F6*107 | 6" 152.4 | 107.56" (2732mm) | 48.38" (1289mm) | 155.94" (3961mm) |
| S63DC-97-111 | 3TG F6*111 | 6'' 152.4 | 111" (2819mm) | 49.94" (1268mm) | 160.94" (4087mm) |
| S63DC-102-120 | 3TG F6*120 | 6'' 152.4 | 120" (3048mm) | 53.5" (1359mm) | 173.5" (4407mm) |
| S63DC-97-123 | 3TG F6*123 | 6'' 152.4 | 123" (3124mm) | 54.94" (1395mm) | 177.94" (4519mm) |
| S63DC-102-126 | 3TG F6*126 | 6'' 152.4 | 126.31"(3208mm) | 54.56" (1386mm) | 180.87" (4594mm) |
| S63DC-101-140 | 3TG F6*140 | 6'' 152.4 | 140.25" (3562mm) | 59.81" (1519mm) | 200.06" (5081mm) |
| S64DC-12-135 | 4TG F6*135 | 6'' 152.4 | 135" (3429mm) | 47.19" (1199mm) | 182.19" (4628mm) |
| S64DC-14-156 | 4TG F6*156 | 6'' 152.4 | 156" (3962mm) | 53.62" (1362mm) | 209.62" (5324mm) |
| S73DC-66-110 | 3TG F7*110 | 7" 177.8 | 110.63" (2810mm) | 50.06" (1271mm) | 160.69" (4081mm) |
| S73DC-66-120 | 3TG F7*120 | 7" 177.8 | 120" (3048mm) | 53.12" (1349mm) | 173.12" (4397mm) |
| S73DC-66-124 | 3TG F7*124 | 7" 177.8 | 124.88" (3172mm) | 54.81" (1392mm) | 179.69" (4564mm) |
| S73DC-66-129 | 3TG F7*129 | 7" 177.8 | 129" (3277mm) | 56.5" (1435mm) | 185.5" (4712mm) |
| S73DC-66-140 | 3TG F7*140 | 7" 177.8 | 140.44" (3567mm) | 60" (1524mm) | 200.44" (5091mm) |
| S73DC-66-150 | 3TG F7*150 | 7" 177.8 | 150" (3810mm) | 63.50" (1613mm) | 213.50" (5423mm) |
| S74DC-74-120 | 4TG F7*120 | 7" 177.8 | 120" (3048mm) | 44.12" (1120mm) | 164.12" (4168mm) |
| S74DC-74-135 | 4TG F7*135 | 7" 177.8 | 135" (3429mm) | 48.43" (1230mm) | 183.44" (4659mm) |
| S74DC-74-140 | 4TG F7*140 | 7" 177.8 | 140" (3556mm) | 49.75" (1263mm) | 189.75" (4819mm) |
| S74DC-74-156 | 4TG F7*156 | 7" 177.8 | 156" (3962mm) | 53.75" (1365mm) | 209.75" (5327mm) |
| S74DC-74-161 | 4TG F7*161 | 7" 177.8 | 161.75" (4108mm) | 55.31" (1405) | 217.06" (5513mm) |
| S74DC-74-167 | 4TG F7*167 | 7" 177.8 | 167" (4242mm) | 56.38" (1432mm) | 223.38" (5674mm) |
| S74DC-74-180 | 4TG F7*180 | 7" 177.8 | 180" (4572mm) | 61.12" (1552mm) | 241.12" (6124mm) |
| S84DC-66-148 | 4TG F8*148 | 8" 203.2 | 147.75" (3753mm) | 51.50" (1308mm) | 199.25" (5061mm) |
| S84DC-66-156 | 4TG F8*156 | 8" 203.2 | 156" (3962mm) | 53.75" (1365mm) | 209.75" (5327mm) |
| S84DC-66-161 | 4TG F8*161 | 8" 203.2 | 160" (4064mm) | 55.75" (1416mm) | 215.75" (5480mm) |
| S84DC-66-170 | 4TG F8*170 | 8" 203.2 | 170" (4318mm) | 57.25" (1454mm) | 227.25" (5481mm) |
| S84DC-66-180 | 4TG F8*180 | 8" 203.2 | 180" (4572mm) | 59.75" (1518mm) | 239.75" (6090mm) |
| 3 4 Stage FC type hydraulic cylinder | |||||
| MODEL NO. | Stage | Largest Stage Diameter | Stroke | The largest sleeve OD | Mounting distance |
| FC-3-110-3205 | 3 | 110 | 3205 | 168 | 343 |
| FC-3-110-3460 | 3 | 110 | 3460 | 168 | 343 |
| FC-3-129-2980 | 3 | 129 | 2980 | 218 | 343 |
| FC-3-129-3205 | 3 | 129 | 3205 | 218 | 343 |
| FC-3-129-3460 | 3 | 129 | 3460 | 218 | 343 |
| FC-3-129-3880 | 3 | 129 | 3880 | 218 | 343 |
| FC-3-129-4270 | 3 | 129 | 4270 | 218 | 343 |
| FC-4-129-4280 | 4 | 129 | 4280 | 218 | 343 |
| FC-4-129-4280 | 4 | 129 | 4280 | 218 | 343 |
| FC-4-129-5180 | 4 | 129 | 5180 | 218 | 343 |
| FC-4-149-3680 | 4 | 149 | 3680 | 218 | 343 |
| FC-4-149-3980 | 4 | 149 | 3980 | 218 | 343 |
| FC-4-149-4280 | 4 | 149 | 4280 | 244 | 343 |
| FC-4-149-4620 | 4 | 149 | 4620 | 244 | 343 |
| FC-4-149-4940 | 4 | 149 | 4940 | 244 | 343 |
| FC-4-149-5180 | 4 | 149 | 5180 | 244 | 343 |
| FC-4-149-5460 | 4 | 149 | 5460 | 244 | 343 |
| FC-4-169-4280 | 4 | 169 | 4280 | 244 | 343 |
| FC-4-169-4620 | 4 | 169 | 4620 | 244 | 343 |
| FC-4-169-4940 | 4 | 169 | 4940 | 244 | 343 |
| FC-4-169-5180 | 4 | 169 | 5180 | 244 | 343 |
| FC-4-169-5460 | 4 | 169 | 5460 | 244 | 343 |
Our Motto:
Supply the safest cylinder to our customers, we exceed your expectations.
Honest, Innovation, Quality, Competitive price and prompt delivery.
We're looking forward the cooperation.
Good Choice for Our Hydraulic Cylinder:
1. Merge together with Europe security idea
Our whole set hydraulic cylinder system with multi-protection can protect the safety of worker &truck and cargo.
2. Specialized system configuration
Specialized system configuration that greatly improve work efficiency and reduce system weight.
3. Custom made is available
We can design different hydraulic system for truck, lifting platform, construction machine, engineering machine, marine and so on.
