Double Acting Hydraulic Oil Cylinder with Piston Rod Used in Engineering Machinery

Rollover cylinder is a single-acting multi-stage hydraulic cylinder, the main role in the trailer, semi-trailer modification, dump truck rollover compartment lift cylinder. Reasonable design, compact structure. Production of a spherical hinge shaft, earrings hinge shaft and other connections, a variety of processes to choose from.Single-acting multi-stage telescopic sleeve hydraulic cylinder, with small size, large stroke and other advantages, can be used for heavy vehicles, agricultural vehicles and other vehicles tilting the bucket lift cylinder.

Multi-stage hydraulic cylinder for large stroke and installation distance or total length (stroke can be greater than the installation distance or total length) occasions.The series of hydraulic cylinder working pressure, working stroke, installation distance, the use of series, all levels of stroke and piston rod diameter and other parameters can be designed according to customer needs.

Certainly, you can provide drawing and product photos so that we can understand your meaning more conveniently, or you can also send us sample and we produce for you according to your sample.

Quality Control:
1. External Inspection: Purchased Item Inspection, Outsourcing Item Inspection

2. Process Inspection: First Inspection, Random Inspection, Handover Inspection

3. Final Quality Inspection: External Dimensions Inspection, 100% Hydraulic Test

4. Type Inspection
Every piece of hydraulic cylinder are tested and will send out only after they are pasted the each test.
Our company has abundant technical force and perfect testing means. By making wide technical and business cooperation with many related enterprises, universities, colleges and institutes both at home and abroad, and employing senior engineers and software engineers, we have greatly strengthened and improved our designing, processing, and testing abilities.

Warranty & Service:
We offer 12 months warranty.
As our hydraulic cylinders, hydraulic cylinder parts, such as the piston rod; Shenzhen DALLAST offers one of the best standard products warranties in this industry. We use of defective materials for normal use when properly maintained for 12 months from the date of shipment in normal use and service.

Features & Benefits:

1. Custom sizes available

2. Stroke lengths 2000mm and longer

3. Designs up to 10000 psi working pressure

4. Total weights can often reach nearly 25,000 pounds

5. High yield carbon or alloy steel outer tubes

6. 001" minimum chrome plated carbon or alloy steel rods

7. Options for ductile iron or bronze inlaid steel rod glands

8. Cushioning at both ends of stroke

9. Mounting alternatives include trunnion mount, clevis, pineyes, or lugs with spherical bearings

10. Custom options for ports and integrated valves

11. Diverse preferences for seals due to temperature

12. Linear transducers, proximity switches, and sensors available

13. Extensive pressure testing

14. Finished cylinder is sandblasted and painted to customer specifications

15. Hydrostatic testing data packets and material test reports available

16. Seal kits available for quick shipment

17. Short manufacturing lead times
