HA-FE13BG-S1  Description

HA-FE13BG-S1 Key Features

• •
  High Performance & High Torque:​ The 400W motor provides substantial power, which is amplified by the gearhead to achieve very high output torque (up to 107 N·m).
• •
  High Resolution Encoder:​ Features a 24-bit high-resolution encoder (16,777,216 pulses/rev) for extremely precise position control, minimal settling time, and stable operation at low speeds.
• •
  Low Cogging & Vibration:​ Advanced design techniques minimize cogging (torque ripple), ensuring exceptionally smooth rotation, which is critical for precision applications like coating or dispensing.
• •
  High Rigidity Gearhead (GR-S-10):​ The planetary gearhead offers high torsional stiffness and excellent durability, ensuring accurate positioning with minimal backlash.
• •
  Compact and Lightweight Design:​ The motor and gearhead combination is designed to save space and reduce the overall weight of the mechanical system.
• •
  Electromagnetic Brake (Suffix -S1):​ The motor includes an integral electromagnetic brake for safety and holding loads in place during power loss, essential for vertical axes.

HA-FE13BG-S1 Material & Applications

• •
  Material:​ The motor housing is typically aluminum alloy for effective heat dissipation. The shaft is hardened steel. The gearhead features high-strength steel gears and a durable housing.
• •
  Primary Applications:
  • •
    Industrial Robots (Articulated, SCARA, Delta)
  • •
    Automated Assembly and Transfer Systems
  • •
    Packaging Machinery
  • •
    Machine Tool Auxiliary Axes
  • •
    Material Handling (Conveyors, Indexing Tables)
  • •
    Semiconductor and Electronic Component Manufacturing Equipment

HA-FE13BG-S1 Key Parameters
