ACS580-01-09A5-4 + J400 ABB Variable Frequency Inverter -10°C To 50°C 50hZ/60hZ

ACS580-01-09A5-4 + J400 ABB Variable Frequency Inverter -10°C To 50°C 50hZ/60hZ

• Optimized Package (Drive + Motor):​ Pre-selected and matched for optimal performance, reliability, and energy savings, simplifying selection, commissioning, and maintenance.
• All-compatible Design (ACS580):​ The drive is compatible with all major fieldbus protocols (via optional modules) and supports sensorless vector control (SLVC) and Direct Torque Control (DTC) for precise speed and torque regulation.
• Intuitive Control & Setup:​ Features the built-in "Drive composer" touchscreen control panel with plain text menus, application macros, and guided startup wizards for quick and easy commissioning.
• High Energy Efficiency:​ The ACS580 includes an "Energy optimizer" function that automatically minimizes motor losses, while the J400 motor is designed for high IE3/IE4 efficiency levels, significantly reducing total lifecycle energy consumption.
• Robust Motor Construction (J400):​ Features a cast iron frame and end shields for superior mechanical strength, heat dissipation, and corrosion resistance in harsh environments. It is designed for inverter duty with insulated bearings and enhanced insulation systems to withstand voltage spikes.
• Safety & Reliability:​ The drive includes built-in functional safety features (Safe torque off, STO) as standard. The package ensures reliable operation with features like pump and fan protections, flying start, and automatic error reset.
• Compact Footprint:​ The ACS580 offers a compact, space-saving design, and the J400 motor provides high power density, minimizing the overall installation footprint.

• Main Materials (ACS580 Drive):
  • Enclosure:​ Powder-coated steel (IP21/UL Type 1) or optional higher IP ratings.
  • Heat Sink:​ Aluminum.
  • PCBs:​ FR4 with conformal coating for protection.
• Main Materials (J400 Motor):
  • Frame & End Shields:​ Cast iron (IM B3, IM B5, IM B35 mountings).
  • Shaft:​ High-strength steel.
  • Stator & Rotor:​ High-grade electrical steel laminations, copper windings (Class F insulation, 155°C).
  • Bearings:​ Insulated bearings (DE) to prevent bearing currents from VFD operation.
  • Fan & Cowl:​ Aluminum/plastic.
• Primary Applications:
  • HVAC Systems:​ Chilled water pumps, cooling tower fans, air handling unit (AHU) fans.
  • Water & Wastewater:​ Clean water supply pumps, booster pumps, wastewater transfer and aeration pumps.
  • Industrial Processes:​ Industrial fans, exhaust systems, centrifugal compressors, conveyor systems.
  • General Industrial Machinery:​ Any application requiring reliable variable speed control of a standard 3-phase induction motor.
