176449-02 Bently Nevada Redundant Power Supply Module 50-60Hz 12/24VDC (0.5A)

176449-02 Description

176449-02 Key Features

• 4-Channel Universal Input: Supports simultaneous connection to up to four proximity, velocity, or acceleration transducers for multi-parameter monitoring.
• Dual-Function Channel Pairing: Channels are programmable in pairs, capable of executing two distinct monitoring functions concurrently (e.g., vibration & thrust position).
• Wide Measurement Coverage: Programmable for radial vibration, axial thrust position, differential expansion, shaft eccentricity, REBAM (bearing wear), absolute shaft vibration, and speed.
• High-Sensitivity Signal Processing: Offers selectable measurement sensitivities for high-precision detection of minute mechanical changes.
• Full Electrical Isolation: Galvanic isolation between input channels and system backplane for superior noise immunity and equipment protection.
• Configurable Alarm Logic: On-board alarm processing with user-definable setpoints, providing independent alarm, danger, and shutdown relay outputs.
• Advanced Signal Conditioning: Built-in filtering, amplification, and linearization for optimal signal accuracy across a broad frequency spectrum (up to 50 kHz).
• Standard Rack Mounting: Designed for seamless integration into standard industrial monitoring racks, supporting hot-swappable installation.
• LED Diagnostic Indicators: Front-panel LEDs for power, channel status, and alarm conditions to facilitate rapid system diagnostics.
• Wide Environmental Tolerance: Operates reliably under extreme temperatures and harsh industrial conditions with high resistance to vibration and shock.
• Low Power Consumption: Energy-efficient design (typical 7.7W) suitable for continuous, long-term operation.
• Industry Standard Compliance: Fully compliant with global industrial safety, EMC, and environmental standards.

176449-02 Materials & Applications

Materials

• Housing & Chassis: Rugged, corrosion-resistant aluminum alloy frame with flame-retardant thermoplastic front panel, ensuring structural rigidity and EMI shielding.
• Circuit Board: High-grade, temperature-stable FR-4 glass epoxy PCB with multi-layer design and SMT components for enhanced reliability.
• Connectors: Industrial-grade, gold-plated BNC and terminal block connectors for low-contact resistance and stable signal transmission.
• Internal Electronics: High-stability precision op-amps, opto-isolators, and industrial-grade microcontrollers for accurate signal conversion and processing.
• Front Panel: Hard-coated anodized aluminum with silk-screened labels and long-life LED indicators for clear status visualization.

Typical Applications

• Power Generation: Turbines (steam, gas, hydro), generators, turbines, and large auxiliary pumps in thermal and hydroelectric power plants.
• Oil & Gas: Centrifugal compressors, gas turbines, expanders, pumps, and motors in refineries and offshore platforms.
• Petrochemical & Chemical: Critical rotating machinery including reformers, extruders, blowers, and large process pumps.
• Steel & Metal Processing: Rolling mills, fan assemblies, gearboxes, and large motors in steel production lines.
• Pulp & Paper: Turbines, dryer cans, calenders, and high-speed process rolls in paper manufacturing facilities.
• Mining & Minerals: Crushers, mills, conveyors, and large dredge pumps in mining operations.
• Marine: Propulsion turbines, turbochargers, and auxiliary engines on large commercial vessels.
• Cement & Lime: Kiln drives, fans, and roller presses in cement production.

176449-02 Important Parameters
