145988-02 BENTLY NEVADA Redundant Power Supply Module 5 V DC/3 A 12V DC
Price:
Contact
MOQ:
1
Delivery Time:
3-5DAYS
Brand:
BENTLY NEVADA
Product Description
145988-02 BENTLY NEVADA Redundant Power Supply Module 5 V DC/3 A 12V DC
145988-02 Description
The 145988-02 is a high-reliability, dual-channel relay output module engineered for integration within industrial machinery protection and condition monitoring systems. Designed as a compact, rack-mountable interface component, it functions as a critical signal actuator, converting system-level alarm and shutdown commands into isolated, fail-safe electrical switching actions for external control circuits. This module provides two independent, optically isolated single-pole double-throw (SPDT) relay outputs, engineered for dependable operation in extreme industrial environments where precision, isolation, and long-term stability are essential for safeguarding critical rotating equipment and process systems.
145988-02 Key Features
- Dual Independent Relay Channels: Two fully isolated SPDT relay outputs for separate alarm, warning, or shutdown control functions.
- High-Galvanic Isolation: Optoelectronic isolation between input logic, relay channels, and external loads for superior noise immunity and system protection.
- Fail-Safe Operation: Configurable for normally energized (de-energize to trip) or normally de-energized (energize to trip) logic to meet diverse safety interlock requirements.
- Wide Load Compatibility: Supports a broad range of AC and DC control voltages and load types for versatile industrial integration.
- Compact Rack-Mount Form Factor: Slim, half-height design for efficient use of standard monitoring system rack space, supporting hot-swap capability.
- Front-Panel LED Diagnostics: Clear LED indicators for power status and individual channel relay state for quick visual troubleshooting.
- Industrial-Grade Durability: Sealed, rugged construction resistant to vibration, shock, dust, and oil mist common in heavy industrial settings.
- Long Electrical Life: High-quality relay contacts rated for extended mechanical and electrical switching cycles.
- Reverse Polarity & Overvoltage Protection: Built-in circuit protection safeguards against wiring errors and electrical transients.
- Universal Power Compatibility: Operates from a wide-range DC power supply for seamless system integration.
- Global Safety & EMC Compliance: Fully certified to meet international industrial standards for safety, electromagnetic compatibility, and environmental resilience.
145988-02 Materials & Applications
Materials
- Housing & Frame: Robust, lightweight aluminum alloy chassis with a flame-retardant thermoplastic front panel, providing excellent EMI shielding and structural rigidity.
- Printed Circuit Board: High-temperature, low-flammability FR-4 glass epoxy substrate with multi-layer copper tracing and heavy-duty solder masks for enhanced thermal stability.
- Relay Components: Industrial-grade electromechanical relays with gold-plated alloy contacts for low contact resistance, stable switching, and resistance to oxidation.
- Connectors: Corrosion-resistant, gold-plated terminal blocks and card-edge connectors ensuring secure, low-resistance electrical connections.
- Internal Electronics: Precision opto-isolators, voltage regulators, and transient suppression components for signal integrity and component longevity.
- Front Panel: Durable anodized aluminum finish with silk-screened labels and high-intensity, long-life LED status indicators.
Typical Applications
- Power Generation: Turbine/generator safety shutdown systems, alarm annunciation, and interlock control in thermal, hydro, and nuclear power plants.
- Oil & Gas: Compressor, pump, expander, and gas turbine protection in refineries, offshore platforms, and pipeline stations.
- Petrochemical & Chemical: Critical process machinery emergency shutdown (ESD), fault isolation, and safety interlocking.
- Metal & Steel: Rolling mill, fan, gearbox, and furnace fan safety control systems.
- Pulp & Paper: Turbine, dryer can, calender, and process roll protection and interlock systems.
- Marine: Propulsion turbine, turbocharger, and auxiliary engine safety controls on commercial vessels.
- Mining & Mineral Processing: Crusher, mill, conveyor, and dredge pump safety interlock systems.
- Cement Production: Kiln drive, induced draft fan, and roller press shutdown and alarm control.
145988-02 Important Parameters
| Parameter | Specification |
|---|---|
| Model Number | 145988-02 |
| Product Type | Dual Channel Isolated Relay Output Module |
| Number of Outputs | 2 independent isolated SPDT relay channels |
| Relay Configuration | Single-Pole Double-Throw (SPDT), Form C |
| Contact Rating | 5A @ 250V AC / 5A @ 30V DC (resistive load) |
| Contact Material | Gold-plated alloy |
| Electrical Life | ≥ 100,000 operations at rated load |
| Mechanical Life | ≥ 10,000,000 operating cycles |
| Isolation Voltage | 2500V RMS (input to output, channel to channel) |
| Logic Operation | User-selectable: Normally Energized (NE) / Normally De-energized (NDE) |
| Input Logic | Compatible with standard industrial monitoring system DC control signals |
| Power Supply | 24V DC (18–32V DC wide operating range) |
| Power Consumption | 2.2W (typical) |
| Mounting | Standard 19" rack mount (half-height module) |
| Dimensions (W×H×D) | 2.5 x 12.5 x 24.0 cm |
| Weight | Approx. 0.45 kg (0.99 lbs) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | 0–95% RH (non-condensing) |
| Vibration Resistance | 5–150 Hz, 9.8 m/s² (1 g) peak |
| Shock Resistance | 147 m/s² (15 g), 11 ms duration |
| Indicators | Power (PWR), Channel 1 Status (CH1), Channel 2 Status (CH2) LEDs |
| Protection | Reverse polarity, overvoltage, transient surge protection |
| Certifications | UL, cUL, CE (EMC), ATEX (optional), RoHS compliant |
| Compatibility | Designed for use in standard industrial machinery protection monitoring racks |
