136180-01 Bently Nevada Redundant Power Supply Module 100 To 240 V AC 5 V DC/3 A
Price:
Contact
MOQ:
1
Delivery Time:
3-5DAYS
Brand:
Bently nevada
Product Description
136180-01 Bently Nevada Redundant Power Supply Module 100 To 240 V AC 5 V DC/3 A
136180-01 Description
The 136180-01 is a high-performance communication gateway module designed for industrial machinery condition monitoring and protection systems. As a full-height, rack-mountable interface unit, it acts as a critical data bridge, seamlessly transmitting real-time monitored parameters, system statuses, and diagnostic information between the monitoring rack and external process control systems (DCS, PLC, SCADA). It integrates dual communication paths (Ethernet and serial) and supports multiple standard industrial protocols, ensuring robust, high-speed data exchange and system interoperability in demanding industrial environments.
136180-01 Key Features
- Dual Communication Interfaces: Equipped with both Ethernet (TCP/IP) and multi-protocol serial (RS232/RS422/RS485) ports for versatile system connectivity.
- Wide Protocol Support: Compatible with Modbus RTU (serial), Modbus/TCP (Ethernet), and proprietary monitoring system protocols for broad integration.
- Configurable Modbus Registers: Features a flexible register utility for custom or condensed data mapping, optimizing data transmission efficiency.
- Full-Height Rack Mount: Standard full-height module design, compatible with standard 19" monitoring system racks, installable in any available slot.
- High-Speed Data Transfer: Enables rapid, reliable transmission of all critical rack data including vibration, gap, temperature, status, and alarm signals.
- Front-Panel Diagnostics: LED indicators for power, network activity, and module status for quick visual system health checks.
- Industrial-Grade Robustness: Rugged construction designed to withstand high levels of vibration, shock, and extreme temperatures.
- Easy System Configuration: Supports direct Ethernet connection to system configuration software for setup, monitoring, and firmware updates.
- Superior Noise Immunity: Galvanic isolation between communication ports and internal circuitry to protect against electrical interference.
- Global Compliance: Fully certified to meet international industrial safety, EMC, and environmental standards.
136180-01 Materials & Applications
Materials
- Housing & Chassis: Rugged aluminum alloy frame with a durable, flame-retardant thermoplastic front panel for structural rigidity and EMI shielding.
- Circuit Board: High-temperature FR-4 glass epoxy PCB with multi-layer design and industrial-grade surface-mount components.
- Connectors: Industrial-grade RJ45 (Ethernet) and robust terminal blocks (serial) with gold-plated contacts for corrosion resistance and stable connections.
- Front Panel: Anodized aluminum with silk-screened labels and high-intensity, long-life LED status indicators.
- Internal Electronics: Precision microprocessors, high-speed opto-isolators, transient voltage suppressors, and filtering circuits for signal integrity.
Typical Applications
- Power Generation: Integrate turbine/generator monitoring systems with plant DCS for real-time data visualization and control.
- Oil & Gas: Connect compressor, pump, and expander protection systems to SCADA networks in refineries and offshore platforms.
- Petrochemical & Chemical: Transmit critical machinery health data to process control systems for safe and efficient operation.
- Metal & Steel: Interface rolling mill and furnace fan monitoring with factory automation systems.
- Pulp & Paper: Link turbine and dryer monitoring systems to plant-wide control networks.
- Marine: Shipboard propulsion and auxiliary machinery monitoring system integration.
- Mining & Cement: Conveyor, kiln, and mill protection system data communication to central control rooms.
136180-01 Important Parameters
| Parameter | Specification |
|---|---|
| Model Number | 136180-01 |
| Product Type | Communication Gateway Module |
| Form Factor | Full-height, rack-mountable |
| Ethernet Interface | 10BASE-T, RJ45 connector, TCP/IP |
| Serial Interface | RS232 / RS422 / RS485 (software configurable) |
| Supported Protocols | Modbus RTU, Modbus/TCP, Proprietary System Protocol |
| Data Transfer Rate | Up to 10 Mbps (Ethernet), Up to 115.2 kbps (Serial) |
| Isolation | 2500V RMS (port-to-system) |
| Power Supply | 24V DC (18–32V DC wide range) |
| Power Consumption | ≤ 10W (typical) |
| Dimensions (W×H×D) | 2.5 × 25.0 × 24.0 cm |
| Weight | Approx. 0.85 kg |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | 0–95% RH (non-condensing) |
| Vibration Resistance | 5–150 Hz, 9.8 m/s² (1 g) peak |
| Shock Resistance | 147 m/s² (15 g), 11 ms duration |
| Indicators | Power (PWR), Network Status (NET), Module Status (STS) LEDs |
| Protection | Overvoltage, reverse polarity, transient surge protection |
| Certifications | UL, cUL, CE (EMC), RoHS compliant |
| Compatibility | For use in standard industrial machinery condition monitoring racks |
