140471-01 Bently Nevada Redundant Power Supply Module 24 V 2x10A 50-60Hz
Price:
Contact
MOQ:
1
Delivery Time:
3-5DAYS
Brand:
Bently Nevada
Product Description
140471-01 Bently Nevada Redundant Power Supply Module 24 V 2x10A 50-60Hz
140471-01 Description
The 140471-01 is a high-performance, 4-channel I/O module designed for industrial machinery protection and condition monitoring systems. As a full-height, rack-mountable unit with integrated internal terminations, it serves as a critical signal interface for connecting proximity probes and seismic transducers to the monitoring system. This module accurately conditions, processes, and transmits dynamic vibration, shaft position, speed, and displacement signals, enabling precise real-time monitoring and reliable machinery protection for critical rotating equipment.
140471-01 Key Features
- 4 Independent Input Channels: Four fully isolated input channels supporting both proximity and seismic transducer signals.
- Multi-Function Measurement: User-programmable channels for radial vibration, thrust position, differential expansion, eccentricity, acceleration, velocity, and shaft absolute position measurements.
- Internal Signal Termination: On-board terminal blocks eliminate need for external wiring panels, simplifying installation and reducing signal noise.
- High Precision Signal Conditioning: Advanced circuitry for low-noise amplification, filtering, and conversion of raw transducer signals.
- Galvanic Isolation: High-level electrical isolation between channels and system electronics for enhanced noise immunity and safety.
- Front-Panel LED Diagnostics: OK, TX/RX communication, and bypass status LEDs for quick visual monitoring.
- Wide Frequency Response: Optimized bandwidth for accurate dynamic measurement across typical machinery operating ranges.
- Industrial Durability: Rugged construction resistant to high vibration, shock, and extreme temperatures.
- Flexible Configuration: Fully programmable via system software for custom alarm setpoints and measurement parameters.
- Hot-Swap Compatible: Supports installation/removal without full system shutdown for maintenance convenience.
- Global Compliance: Meets international industrial standards for safety, EMC, and performance.
140471-01 Materials & Applications
Materials
- Housing: Robust aluminum alloy chassis with durable anodized finish for structural rigidity and EMI shielding.
- Circuit Board: High-temperature FR-4 glass epoxy multi-layer PCB with industrial-grade surface-mount components.
- Connectors: Gold-plated, corrosion-resistant terminal blocks and card-edge connectors for reliable connections.
- Front Panel: Flame-retardant thermoplastic with silk-screened labels and high-intensity LED indicators.
- Internal Electronics: Precision op-amps, analog-to-digital converters, opto-isolators, and transient voltage suppressors.
Typical Applications
- Power Generation: Turbine, generator, and boiler feed pump vibration and position monitoring in thermal, hydro, and nuclear plants.
- Oil & Gas: Compressor, expander, pump, and gas turbine protection in refineries and offshore platforms.
- Petrochemical & Chemical: Critical process machinery health monitoring for reactors, compressors, and centrifuges.
- Metal & Steel: Rolling mill, fan, gearbox, and furnace drive vibration monitoring.
- Pulp & Paper: Turbine, dryer can, and calender equipment protection.
- Marine: Shipboard propulsion turbine and turbocharger condition monitoring.
- Mining & Cement: Crusher, mill, kiln, and conveyor drive machinery health monitoring.
140471-01 Important Parameter
| Parameter | Specification |
|---|---|
| Model Number | 140471-01 |
| Product Type | 4-Channel Prox/Velom I/O Module with Internal Terminations |
| Form Factor | Full-height, rack-mountable |
| Number of Channels | 4 independent isolated input channels |
| Supported Transducers | Proximity probes, seismic (velocity/acceleration) transducers |
| Input Voltage Range | Proximity: ±10 V; Seismic: ±500 mV |
| Input Impedance | 10 kΩ (standard) |
| Isolation Voltage | 1500 V DC (channel-to-system) |
| Frequency Response | 10 Hz to 1 kHz (typical) |
| Signal-to-Noise Ratio | >70 dB |
| Measurement Accuracy | Voltage: ±0.1%; Current: ±0.2%; Frequency: ±0.1% |
| Power Supply | 24 V DC (18–32 V DC wide range) |
| Power Consumption | 7.7 W (typical) |
| Dimensions (H×W×D) | 241.3 × 24.4 × 99.1 mm |
| Weight | Approx. 0.91 kg |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -55°C to +125°C |
| Operating Humidity | 0–95% RH (non-condensing) |
| Vibration Resistance | 5–150 Hz, 9.8 m/s² (1 g) peak |
| Shock Resistance | 147 m/s² (15 g), 11 ms duration |
| Indicators | OK, TX/RX, Bypass LEDs |
| Protection | Overvoltage, reverse polarity, transient surge protection |
| Certifications | CE, CSA, ATEX (optional), RoHS compliant |
| Mounting | Standard 19" monitoring system rack (full-height slot) |
